Whirlpool KECC566RBL03 Parts List

Search Model by Keyword(s):

Popular Searches: (Click to search)    1200w  cooking  crt  ctr  dual  element  energuide  french  front  ground  infinite  label  rear  safer  screw  surface  switch  tips


Select a Diagram


01 - Cooktop Parts, Optional Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item # Part # Description Price / Availability Add to Cart
1 8286608 Use & Care Guide Call for Availability
8286066 Instruction Installation Call for Availability
8304571 Instrctions-canada Call for Availability
8286074 Wiring Diagram Call for Availability
8286062 Energuide Label Call for Availability
3191638 Safer Cooking Tips (english) Call for Availability
9759133 Safer Cooking Tips (french) Call for Availability
2 8286972 Cooktop, Glass (white) Call for Availability
W10739033 W10739033 Cooktop, Glass (black) Call for Availability
3 WP486754 Screw Call for Availability
4 8285808 Bracket, Switch Call for Availability
5 W10142239 Frame, Cooktop (stainless Only) Call for Availability
6 9759094 Spring Locator (10) Call for Availability
7 WP8286070 WP8286070 Switch, Infinite (triple-lf) Call for Availability
WP3191050 WP3191050 Switch, Infinite (1500w Rr) Call for Availability
WP3191049 WP3191049 Switch, Infinite (1200w Lr-crt Rear)
(Replaces: 3191049) 		Call for Availability
WP4456027 Switch, Infinite (dual-ctr Front)   (Replaces: 4456027) Call for Availability
8 8285469 Seal, Switch Shaft Call for Availability
9 W10491985 W10491985 Screw
(Replaces: 3196160) 		Call for Availability
10 WP8286096BL Knob, Control (5) (black) Call for Availability
8286096WH Knob, Control (5) (white) Call for Availability
8286096CM Knob, Control (5) (cashmere) Call for Availability
11 8286556 Box, Burner Call for Availability
12 9760762 Shield, Heat Call for Availability
13 W10180227 Shield, Heat Control Call for Availability
14 WP3196557 WP3196557 Screw Call for Availability
15 3183956 Seal, Switch Cover Call for Availability
16 8286426 Seal, Heat Shield Call for Availability
18 8186533 Bracket, Mounting Call for Availability
19 WP3400093 Screw   (Replaces: 3400093) Call for Availability
20 9763517 Rail, Element Call for Availability
21 8286345 Rail, Element Call for Availability
22 8286056 Lamp, Hot Surface Indicator Call for Availability
24 8285846 Element, Surface (triple Lf) Call for Availability
W10823695 W10823695 Element, Surface (4300w Center) Call for Availability
W10823711 W10823711 Element, Surface (1200w - Lr)
(Replaces: WP8523698 8523698) 		Call for Availability
W10823699 W10823699 Element, Surface (1500w - Rr) Call for Availability
242824 Wire (14 Ga. 150 C Orange) Call for Availability
242823 Wire (14 Ga. 150 C Green) Call for Availability
8286607 Grommet-flexible Call for Availability
8286582 Clip, Bridge (3) Call for Availability
W10491984 Seal, Switch Call for Availability
WP3400015 Screw Ground, Burner Box Call for Availability
8286422 Conduit, Harness Call for Availability
8286382 Clip, Harness Call for Availability
8286418 Harness, Main Call for Availability
242827 Wire (14 Ga. 150 C Yellow) Call for Availability
242831 Wire (14 Ga. 200 C Red) Call for Availability
242825 Wire (14 Ga. 150 C Red) Call for Availability
242830 Wire (14 Ga. 200 C Brown) Call for Availability
242822 Wire (14 Ga. 150 C Brown) Call for Availability
242828 Wire (12 Ga. 150 C Black) Call for Availability
4456028 Wire, Jumper Call for Availability
WP8286642 WP8286642 Tape, Foam Call for Availability
W10491985 W10491985 Screw, Ground
(Replaces: 3196160) 		Call for Availability
242820 Wire (14 Ga. 150 C Black) Call for Availability
