Maytag MAH3000BGW Parts List

Popular Searches: (Click to search)    assy  belt  boot  conversion  door  drain  hose  isolator  kit  lip  motor  neptune  seal  spinner  support  svc  switch  tub  watt  wax


Select a Diagram

01 - Base

02 - Cabinet-front

03 - Cabinet-rear

04 - Control Panel

05 - Door & Front Panel

06 - Latch Assembly Parts List

07 - Motor & Motor Control

08 - Outer Tub

09 - Spinner Assembly & Outer Tub Cover

10 - Top

11 - Wiring Information

12 - Wiring Information

Select Diagram ... 01 - Base 02 - Cabinet-front 03 - Cabinet-rear 04 - Control Panel 05 - Door & Front Panel 06 - Latch Assembly Parts List 07 - Motor & Motor Control 08 - Outer Tub 09 - Spinner Assembly & Outer Tub Cover 10 - Top 11 - Wiring Information 12 - Wiring Information

04 - Control Panel   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WP22002010	Hose, Air Dome (Series: 10)	$44.50 Special Order
2	WP22001664	Timer Knob Insert/cap (wht) (Series: 10) (Replaces: 22001664)	$4.80  In-Stock Retail: $4.59
3	22002275	Panel, Control (wht) (Series: 10)	Call for Availability
4	22003619	Switch, Temp. 4 Pos. (wht) (Series: 10)	$67.30 Special Order
5	22003620	Switch, Options (wht) (Series: 10)	$40.50 Special Order
6	22002529	Console Back Panel (Series: 10)	$12.90 Special Order
	8534058	Screw (Series: 10)	$6.70 Special Order
	WP489128	Screw (Series: 10)	$6.70 Special Order
7	22002560	Switch, Push To Start (Series: 10)	Call for Availability
8	22002006	Clip (Series: 97)	Call for Availability
	22003820	Wire Harness / Hh / Unbalance (Series: 77)	$55.60 Special Order
	22003823	Wire Harness (Series: 77)	$92.90 Special Order
	22003823	Wire Harness (Series: 84)	$92.90 Special Order
	22003836	Harness, Upper Sub Assy,venus (Series: 97)	$57.10 Special Order
	22003820	Wire Harness / Hh / Unbalance (Series: 84)	$55.60 Special Order
	22002644	Wire Harness, Main (Series: 10)	$173.10 Special Order
9	8534058	Screw (Series: 10)	$6.70 Special Order
	22002992	Timer (Series: 10)	Call for Availability
10	22002282	Bezel, Timer Dial (wht) (Series: 10)	$4.40 Special Order
11	WP22001659	Timer Knob - Grey (Series: 10) (Replaces: 22001659)	$15.90  In-Stock Retail: $15.49
12	22002917	Board, Control (50hz) (Series: 10)	Call for Availability
	22002287	Screw, Machine Control (Series: 10)	$4.40 Special Order
	M0282005	Locknut (Series: 10)	$5.00 Special Order
13	22002994	Switch, Pressure (Series: 10)	Call for Availability
14	22003621	Switch, Fabric (wht) (Series: 10)	$40.50 Special Order
15	22002284	Bracket (Series: 10)	$4.40 Special Order
16	27001110	Console (wht) (Series: 10)	$39.70 Special Order
17	WP489128	Screw (Series: 10)	$6.70 Special Order
	22002178	Bracket, Water Switch (Series: 10)	$4.40 Special Order
18	22003708	Manual, Use & Care (Series: 10)	Call for Availability
19	16010061	Manual Kit, Service (Series: 10)	$6.30 Special Order
20	22004082	Seal Insertion Tool (Series: 10)	Call for Availability
