Maytag MAH3000BGW Parts List

Popular Searches: (Click to search)    assy  belt  boot  conversion  door  drain  hose  isolator  kit  lip  motor  neptune  seal  spinner  support  svc  switch  tub  watt  wax


Select a Diagram

01 - Base

02 - Cabinet-front

03 - Cabinet-rear

04 - Control Panel

05 - Door & Front Panel

06 - Latch Assembly Parts List

07 - Motor & Motor Control

08 - Outer Tub

09 - Spinner Assembly & Outer Tub Cover

10 - Top

11 - Wiring Information

12 - Wiring Information

Select Diagram ... 01 - Base 02 - Cabinet-front 03 - Cabinet-rear 04 - Control Panel 05 - Door & Front Panel 06 - Latch Assembly Parts List 07 - Motor & Motor Control 08 - Outer Tub 09 - Spinner Assembly & Outer Tub Cover 10 - Top 11 - Wiring Information 12 - Wiring Information

01 - Base   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	22003435	Base (Series: 10)	$215.80 Special Order
	22003605	Base Weld Assembly (Series: 72)	$53.60 Special Order
	22003580	Base, Assembly (Series: 67)	$61.20 Special Order
2	22003298	Retainer, Wire (Series: 10)	$6.40 Special Order
3	WP90767	Screw (Series: 10)	$4.80  In-Stock Retail: $4.59
4	WP308605	Clip (Series: 10)	$7.10 Special Order
5	22003709	Pump,drain (50hz) (Series: 77)	$117.70 Special Order
	25001012	Pump Isolator Bracket (Series: 10)	$67.10 Special Order
	22003709	Pump,drain (50hz) (Series: 84)	$117.70 Special Order
	22003635	Pump, High Torque (Series: 80)	$117.30 Special Order
6	WP8563585	Adjustable Leg W/foot & Nut (Series: 10)	$7.80  In-Stock Retail: $7.54
7	WP62739	Nut (Series: 10)	$4.80 Special Order
8	WP210684	Foot, Rubber (Series: 10)   (Replaces: 210684)	$9.30  In-Stock Retail: $9.22
9	22001988	Strut Assy-rear (Series: 10)	Call for Availability
10	22003080	Clip, Airdome Hose (Series: 10)	$4.40 Special Order
11	22002477	Shield, Transformer (Series: 10)	$20.40 Special Order
	WP22003778	Transformer (Series: 82)   (Replaces: 22003778)	$136.70 Special Order
	WP33001882	Screw, Self Drilling (Series: 10)	$52.00 Special Order
	22002476	Transformer (Series: 10)	$109.00 Special Order
12	WP22003262	Hose, Tub To Pump (Series: 84) (Replaces: 22003262)	$39.40 Special Order
	WP22003262	Hose, Tub To Pump (Series: 77) (Replaces: 22003262)	$39.40 Special Order
13	WP696392	Clamp, Sump Hose (Series: 77)	$4.40 Special Order
	WP696392	Clamp, Sump Hose (Series: 84)	$4.40 Special Order
14	WP285655	Clamp, Drain Hose (Series: 84)	$4.80  In-Stock Retail: $4.59
15	22003261	Plug, Outer Tub (Series: 77)	$4.50 Special Order
	22003261	Plug, Outer Tub (Series: 84)	$4.50 Special Order
16	WP285655	Clamp, Outer Tub Plug (Series: 77)	$4.80  In-Stock Retail: $4.59
	WP285655	Clamp, Outer Tub Plug (Series: 84)	$4.80  In-Stock Retail: $4.59
17	22003265	Bag, Plastic W/drawstring (Series: 84)	Call for Availability
	22003265	Bag, Plastic W/drawstring (Series: 77)	Call for Availability
	22003727	Pressure Switch, Pump Mounted (Series: 84)	$74.90 Special Order
	22003727	Pressure Switch, Pump Mounted (Series: 77)	$74.90 Special Order
18	WP285655	Clamp, Hose (Series: 77)	$4.80  In-Stock Retail: $4.59
	WP285655	Clamp, Hose (Series: 84)	$4.80  In-Stock Retail: $4.59
19	22003268	Cap, Rubber (Series: 77)	$19.70 Special Order
	22003268	Cap, Rubber (Series: 84)	$19.70 Special Order
