Whirlpool KBMC147HBT0 Parts List

Popular Searches: (Click to search)    black  fuse  lamp  magnetron  model  motor  paint  pressurized  screw  sealer  silastic  spray  spring  stainless  steel  switch  torsion  touch  transformer  white


Select a Diagram

01 - Oven, Literature

02 - Control Panel

03 - Microwave Compartment

04 - Cabinet And Stirrer

05 - Top Venting

06 - Microwave Door, Optional

Select Diagram ... 01 - Oven, Literature 02 - Control Panel 03 - Microwave Compartment 04 - Cabinet And Stirrer 05 - Top Venting 06 - Microwave Door, Optional

02 - Control Panel   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	4452602	Panel, Control (black)	$211.70 Special Order
	4452603	Panel, Control (white)	Call for Availability
	4452973	Panel, Control (biscuit)	$200.70 Special Order
	4451790	Panel, Control (stainless)	$205.60 Special Order
2	4456878	Switch, Membrane (black)	$243.10 Special Order
	4456879	Switch, Membrane (white)	$271.80 Special Order
	4456882	Switch, Membrane (biscuit)	$475.40 Special Order
	4456876	Switch, Membrane (stainless)	$214.40 Special Order
3	4452248	Insulation, Board	Call for Availability
4	4452249	Insulation, Board Support	Call for Availability
5	4452260	Spacer, Foam	$14.80 Special Order
6	4452345	Insulator, Dialectric	Call for Availability
7	4453167	Microcomputer	$368.10 Special Order
8	3400406	Screw	Call for Availability
9	WP3400832	Screw (Replaces: 3400832)	$4.80  In-Stock Retail: $4.59
