06 - Freezer Door And Basket Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	L2300085	Freezer Door Panel (includes Item 9)	$508.40 Special Order
2	2204525	Divider, Basket	$34.60 Special Order
3	2207429	Clamp, Divider	$15.50 Special Order
4	2207415	Nut, Crimp	$8.70 Special Order
5	W10005070	Screw	$8.70 Special Order
6	2005400	Filler, Foam	$74.90 Special Order
7	2300027	Spacer, Door Edge - Side	$59.30 Special Order
8	2300025	Spacer, Door Edge Top & Bottom	$40.90 Special Order
9	2302710	Door Gasket, Magnetic	$191.10  In-Stock Retail: $186.43
10	WP308544	Screw, 10-24 X 1/2	$4.80 Special Order
11	WP2005290	Handle, Door (stainless Steel)	$187.70  In-Stock Retail: $183.10
12	W11214482	Roller	$57.00 Special Order
13	W10137182	Skin, Door (stainless Steel)	$743.40 Special Order
14	WP8281250	Screw 8-15 X 1/2 (stainless Steel)	$6.70  In-Stock Retail: $6.50
	W10851443	Screw 8-15 X 1/2 (black)	$4.80 Special Order
15	2257426	Bracket Assembly, Freezer Basket	$101.00 Special Order
17	2257442	Basket, Upper	$193.00 Special Order
18	2174124	Pan, Ice Cube	$73.80 Special Order
19	WP2207454	Nut, Hex	$6.70 Special Order
20	2207471	Bushing	$4.40 Special Order
21	3400507	Screw	$4.40 Special Order
22	2257331	Basket, Freezer Lower	$153.70 Special Order
