Whirlpool IJT195300 Parts List

Popular Searches: (Click to search)    assy  beige  bimetal  blade  crisper  defrost  door  fan  gasket  magnetic  mist  paint  pan  pressurized  spray  thermostat  touch  trim  washer  white


Select a Diagram

01 - Cabinet Parts

02 - Door Parts

03 - Liner Parts

04 - Unit Parts

05 - Shelf Parts, Optional Parts

Select Diagram ... 01 - Cabinet Parts 02 - Door Parts 03 - Liner Parts 04 - Unit Parts 05 - Shelf Parts, Optional Parts

04 - Unit Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	2205341	Plate, Unit Mounting	$55.00 Special Order
2	WP489478	Screw	$4.80  In-Stock Retail: $4.59
3	WP2214960	Condenser	$203.40 Special Order
4	WP2315531	Heater, Defrost (Replaces: 2176300)	$107.00  In-Stock Retail: $104.38
5	2195391	Evaporator Assy.	Call for Availability
6	WP8281196	Screw	$4.80  In-Stock Retail: $4.59
7	2172619	Drain Pan	Call for Availability
8	WP4387503	Defrost Bimetal (Replaces: 2182380)	$32.30  In-Stock Retail: $31.42
9	2176301	Bracket, Heater	$4.40 Special Order
10	2163780	Extension, Air Baffle	$4.40 Special Order
11	2201184	Support Block	$4.20 Special Order
12	WP2162358	Cover	$63.30 Special Order
13	WP4387938	Overload (production (includes Relay))	$127.50  In-Stock Retail: $124.30
	WP4387938	Overload (service (includes Relay)) (Replaces: 4387938)	$127.50  In-Stock Retail: $124.30
14	876811	Grommet, (service Compressor) (4)	$4.80 Special Order
	W11661108	Grommet (4) (production)	$9.00 Special Order
15	WP4387938	Relay (production (service See Overload))	$127.50  In-Stock Retail: $124.30
17	WPW10475495	Roller (2) (Replaces: 2150304)	$19.60  In-Stock Retail: $19.05
18	W11594405	Rivet	$11.20  In-Stock Retail: $10.88
19	2182338	Clip, Heater	Call for Availability
20	876811	Screw, Compressor	$4.80 Special Order
28	W10823815	Compressor (includes Items 11, 12, 13, 15, 29, 38) (also Order 482801 Installation Kit & 876765 Tube Kit) (Replaces: 2183471)	$325.00  In-Stock Retail: $317.06
29	W10843121	Drier	$31.80  In-Stock Retail: $30.99
30	WPW10339879	Clamp	$4.80 Special Order
38	WP2172890	Wire Assembly	$4.80 Special Order
39	WP2198921	Air Baffle	$59.00 Special Order
40	W10822259	Motor, Condenser	$208.30  In-Stock Retail: $203.17
42	2187345	Wire Assy. Unit	$45.30 Special Order
43	WP2190685	Fan, Blade (Replaces: 2190685)	$52.60 Special Order
44	WP486692	Nut   (Replaces: 486692)	$4.80 Special Order
45	2212603	Tube, Transition	$28.70 Special Order
46	2205294	Tube, Discharge	$35.80 Special Order
47	2205293	Tube, Suction	$68.60 Special Order
48	W11676464	Tube, Process	$62.30 Special Order
58	978029	Valve Access (5/8``)	$65.50 Special Order
	978030	Valve, Access (3/4``)	$84.20 Special Order
	876764	Valve, Access(3/16``)	$56.70  In-Stock Retail: $55.29
	482278	Start Kit	Call for Availability
	WP978025	Valve, Access (1/4``) (Replaces: 978025)	$65.70  In-Stock Retail: $64.01
	2210451	Evap. Tray	$50.70 Special Order
	978026	Valve, Access (5/16``)	$78.60  In-Stock Retail: $76.67
	978027	Valve, Access (3/8``)	$80.20  In-Stock Retail: $78.20
	978028	Valve, Access (1/2)	Call for Availability
