Maytag LAT8520ABW Parts List

Popular Searches: (Click to search)    bearing  belt  break  clamp  damper  drive  kit  lid  light  lube  pad  poly  pulley  pump  repair  siphon  switch  tub  valve  water


Select a Diagram

01 - Base

02 - Cabinet

03 - Clutch, Brake & Belts

04 - Control Panel

05 - Top

06 - Transmission

07 - Tub

Select Diagram ... 01 - Base 02 - Cabinet 03 - Clutch, Brake & Belts 04 - Control Panel 05 - Top 06 - Transmission 07 - Tub

04 - Control Panel   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WP22001619	Air Dome And Tube	$46.00 Special Order
2	214809	Back Up Plate	$14.60 Special Order
3	215821	Cap, Knob	Call for Availability
4	WP596669	Clamp,water Level Swtch Tube	$4.80 Special Order
5	207603	Control Panel	Call for Availability
6	214897	Pad, Control Panel	$27.00 Special Order
7	207215	End Cap Lh	Call for Availability
8	207216	End Cap Rh	Call for Availability
9	214894	Fastener, End Cap	$4.40 Special Order
10	WP207360	Infinite Level Press Switch (Replaces: 207360)	$107.70 Special Order
11	214872	Palnut, End Cap	Call for Availability
12	WPW10137328	Retainer, Timer Knob (Replaces: 211605)	Call for Availability
13	210932	Screw, No.8 X 9/16 Ctsk	$4.40 Special Order
14	WPW10139210	Screw, No.8 X 5/16 Inch	$4.80  In-Stock Retail: $4.59
15	WP67006908	Screw-temp. Switch To Panel	$4.80 Special Order
16	WP3400014	Screw-timer To Control Pane	$4.80 Special Order
17	WP211065	Spring, Timer Knob (Replaces: 211065)	$4.80 Special Order
18	207377	Timer	Call for Availability
19	215827	Timer Dial Skirt	$8.00 Special Order
20	215828	Knob, Timer (blk)	$7.80 Special Order
21	WP22205033	Timer Motor 120-60	$68.30 Special Order
22	207368	Temp Control Switch - 3 Button	$47.70 Special Order
23	207383	Wire Harness	$38.90 Special Order
