Maytag L3521XRW Parts List

Popular Searches: (Click to search)    bulb  door  element  infinite  leg  leveling  lrg  oven  seal  silicone  sml  switch


Select a Diagram

01 - Body

02 - Control Panel

03 - Door/drawer (xrx Ser Pre 10)

04 - Door/drawer (xrx Ser Pre 24)

05 - Oven/base

06 - Top Assembly

Select Diagram ... 01 - Body 02 - Control Panel 03 - Door/drawer (xrx Ser Pre 10) 04 - Door/drawer (xrx Ser Pre 24) 05 - Oven/base 06 - Top Assembly

02 - Control Panel   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	7737P032-60	Knob, Infinite (blk) (Series: 10)	$10.10 Special Order
2	7407P081-60	Light, Indicator (Series: 10)	Call for Availability
	W10852510	Light, Indicator (Series: 16)   (Replaces: 7407P102-60)	$73.20 Special Order
3	4876S067-59	Panel Assy (blk) (Series: 10)	Call for Availability
	WP74004005	Screw (Series: 10)	$4.80 Special Order
4	WP7101P309-60	Screw (Series: 10)	$4.80 Special Order
	WP7403P255-60	Switch, Selector (Series: 10) (Replaces: 7403P255-60)	$92.00 Special Order
5	3802F087-51	Brace, Lwr Bkgd (Series: 10)	Call for Availability
6	WP3195558	Nut, Speed (Series: 10)   (Replaces: 7103P129-60)	$6.40 Special Order
7	WP7403P239-60	Switch, Infinite (lrg Element) (Series: 10) (Replaces: 7403P239-60)	$33.50  In-Stock Retail: $49.21
	WP7101P309-60	Screw (Series: 10)	$4.80 Special Order
	WP7403P238-60	Switch, Infinite (sml Element) (Series: 10) (Replaces: 7403P238-60)	$40.00  In-Stock Retail: $56.27
8	WP7404P105-60	Thermostat (Series: 10)	$219.60 Special Order
9	7101P317-60	Screw (Series: 10)	$4.40 Special Order
	7726P052-60	End Cap (lt-blk) (Series: 10)	Call for Availability
	7726P051-60	End Cap (rt-blk) (Series: 10)	Call for Availability
10	74002162	Housing, Control Panel (Series: 10)	$11.30 Special Order
	WP59002061	Screw (6abx38-zn) (Series: 10)	$4.80 Special Order
11	W11690131	Lens, Indicator Light (Series: 16)	$4.60 Special Order
	W11690131	Lens, Indicator Light (Series: 10)	$4.60 Special Order
12	3604F201-80	Shield, Sight (Series: 10)	$3.10 Special Order
13	3807F450-45	Support, Control Pnl (lt) (Series: 10)	Call for Availability
	WP7101P338-60	Screw (8bx3/8-ni) (Series: 10)   (Replaces: 7101P338-60)	$4.40 Special Order
	3807F449-45	Support, Control Pnl (rt) (Series: 10)	Call for Availability
14	3418D097-60	Hinge, Main Top (lt) (Series: 10)	Call for Availability
	3418D098-60	Hinge, Main Top (rt) (Series: 10)	$4.40 Special Order
15	7403P067-60	Switch, Rocker (blk) (Series: 10)	$60.50 Special Order
16	WP7101P309-60	Screw (Series: 10)	$4.80 Special Order
	7602P104-60	Clock (Series: 10)	Call for Availability
17	7711P468-60	Button, Set (blk) (Series: 10)	Call for Availability
18	7711P469-60	Button, Slide (blk) (Series: 10)	Call for Availability
19	74001013	Harness, Control/top (Series: 10)	$15.00 Special Order
	5170D145-60	Harness, Control Panel (Series: 10)	Call for Availability
20	8113P030-60	Manual, Use & Care (Series: 10)	Call for Availability
21	16002081	Guide, Quick Ref - Norge (Series: 10)	$22.60 Special Order
