Whirlpool GS460LELQ0 Parts List

Popular Searches: (Click to search) bake black bottom burner door electrode gas igniter module oven paint pressurized screw sensor spark spray touch trim valve white

Select a Diagram

01 - Cooktop Parts

02 - Control Panel Parts

03 - Manifold Parts

04 - Chassis Parts

05 - Drawer & Broiler Parts

06 - Door Parts, Miscellaneous Parts

Double click the image below to zoom-in

Hover over In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability
1	3186189	Endcap, Right Hand (black)	$37.60 Special Order
	3186190	Endcap (left Hand White)	Call for Availability
	8272507	Endcap (left Hand-biscuit)	$31.60 Special Order
	3186188	Endcap, Left Hand (black)	$31.60 Special Order
	3186191	Endcap (right Hand White)	Call for Availability
	8272508	Endcap (right Hand-biscuit)	$37.60 Special Order
2	8523408	Support, Endcap (left Hand)	Call for Availability
	8523409	Support, Endcap (right Hand)	Call for Availability
3	8524101	Panel, Control (biscuit)	$150.60 Special Order
	8524102	Panel, Control (black)	Call for Availability
	8524106	Panel, Control (white)	$136.90 Special Order
4	WP4449746	Screw (Replaces: 4449746)	$4.50 Special Order
5	WPW10331686	Module, Spark (Replaces: 9758080 8273977)	$238.90 In-Stock Retail: $227.43
6	8053505	Shield, Lower Heat	$97.50 Special Order
7	8523412	Bracket, Support	$100.20 Special Order
8	8272474	Cover, Upper	$47.00 Special Order
9	8053910	Shield, Heat	$28.30 Special Order
10	8273132	Cover, Lower	$68.00 Special Order
12	4453607	Control, Range (black)	$281.50 Special Order
	8523301	Control, Range (biscuit)	$359.40 Special Order
	4453606	Control, Range (white)	$281.50 Special Order
13	W11233072	Screw	$8.70 In-Stock Retail: $8.47
14	9755076	Power Supply, Pca	$138.40 Special Order
15	8523000	Jumper W/fuse	$83.40 Special Order
16	WP3196557	Screw (Replaces: 3196169)	$4.80 In-Stock Retail: $4.59
19	WP8273564	Clip	$7.70 Special Order
