Whirlpool GR450LXLB0 Parts List

Popular Searches: (Click to search)    0  12oz  2oz  almond  biscuit  black  cleaner  door  element  foot  glass  hinge  paint  pressurized  screw  spray  superior  surface  touch  white


Select a Diagram

01 - Cooktop Parts

02 - Control Panel Parts

03 - Door And Drawer Parts

04 - Oven Chassis Parts

05 - Oven Parts, Miscellaneous Parts

Select Diagram ... 01 - Cooktop Parts 02 - Control Panel Parts 03 - Door And Drawer Parts 04 - Oven Chassis Parts 05 - Oven Parts, Miscellaneous Parts

01 - Cooktop Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	LIT9752776	Literature Parts (template, Anti-tip)	Call for Availability
	LIT9782643	Literature Parts (wiring Diagram)	Call for Availability
	LIT9782655	Literature Parts (use & Care Guide)	Call for Availability
	LIT3191638	Safer Cooking Tips	Call for Availability
	LIT9757984	Literature Parts (installation Instructions)	Call for Availability
2	WP9780939	Gasket, Cooktop (front & Sides)	Call for Availability
3	9781614	Rear Gasket	Call for Availability
4	9750456PC	Frame, Cooktop (biscuit)	Call for Availability
	9750456PW	Frame, Cooktop (white)	Call for Availability
	9750456PB	Frame, Cooktop (black)	Call for Availability
5	9753674	Support, Element	Call for Availability
6	9752337GC	Back Splash (biscuit)	Call for Availability
	9752337GB	Back Splash (black)	Call for Availability
	9752337GW	Back Splash (white)	Call for Availability
7	9753675	Brace, Support	Call for Availability
8	9753691	Support Clips (4)	Call for Availability
9	238614	Bumper-white (4)	Call for Availability
10	9781935	Hot Light	Call for Availability
11	W10823692	Element, Surface (1000/2400w - Lf) (Replaces: 8523693)	Call for Availability
	W10823699	Element, Surface (1500w - Rr)	Call for Availability
	W10823698	Element, Surface (1800w - Lr-rf) (Replaces: WP8523696 8523696)	Call for Availability
	WP8523700	Element, Surface (warm Zone)	Call for Availability
14	9754088CW	Cooktop, Ceran (white)	Call for Availability
	9754088CC	Cooktop, Ceran (biscuit)	Call for Availability
	9754088CB	Cooktop, Ceran (black)	Call for Availability
15	9781460	Rod, Small Ceran Element	Call for Availability
17	WP9781235	Speed Nut	Call for Availability
18	9781459	Rod, Large Ceran Element	Call for Availability
19	9780585	Wire Guard	Call for Availability
21	9753040CB	Cover, Vent (black)	Call for Availability
	9753040CC	Cover, Vent (biscuit)	Call for Availability
	9753040CW	Cover, Vent (white)	Call for Availability
22	3149190	Clip, Vent Cover	Call for Availability
23	4159388	Screw	Call for Availability
24	486650	Screw	Call for Availability
25	9750767	Gasket	Call for Availability
26	9753677	Spring, Warm Zone Element	Call for Availability
	3149333	Screw	Call for Availability
