Maytag JJW2527WB00 Parts List

Popular Searches: (Click to search)    2oz  appliance  assy  black  blower  bulb  door  glass  limit  lower  mgr  oven  paint  relay  spray  stainless  switch  touch  upper  white


Select a Diagram

01 - Upper Oven Parts

02 - Lower Oven Parts

03 - Upper Oven Door Parts

04 - Lower Oven Door Parts

05 - Internal Oven Parts

06 - Control Panel Parts

07 - Optional Parts

Select Diagram ... 01 - Upper Oven Parts 02 - Lower Oven Parts 03 - Upper Oven Door Parts 04 - Lower Oven Door Parts 05 - Internal Oven Parts 06 - Control Panel Parts 07 - Optional Parts

06 - Control Panel Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	W10401233	Assembly, Control Panel (stainless)	$971.50 Special Order
	W10672343	Assembly, Control Panel (black)	$774.10 Special Order
2	W10811884	Assy., Ui Extended	$336.70 Special Order
3	W10187048	Panel, Control Box Rear	$66.00 Special Order
4	WPW10273666	Blower (lower)   (Replaces: W10273666)	$196.30  In-Stock Retail: $191.48
	WPW10273667	Blower (upper)   (Replaces: W10273667)	$195.20  In-Stock Retail: $190.43
5	W10186997	Bracket, Cooling Fan Upper	$50.60 Special Order
	W10187016	Bracket, Cooling Fan Lower	$50.60 Special Order
6	W10176180	Panel, Control Box Top	$60.20 Special Order
7	W10176003	Panel, Control Box (right Side)	$53.60 Special Order
	W10176002	Panel, Control Box (left Side)	$68.60 Special Order
8	W10176004	Support, Top Cntrl	$10.80 Special Order
9	W10343437	Cable	$73.90 Special Order
10	W10176243	Bracket, Cover (lwr Cooling Fan)	$45.00 Special Order
11	WP90767	Screw	$4.80  In-Stock Retail: $4.59
12	WPW10292568	Mgr., Appliance   (Replaces: W10292568)	$244.10 Special Order
13	WPW10286791	Control, Elec   (Replaces: W10286791)	$178.90  In-Stock Retail: $178.89
14	WP9752759	Relay (Replaces: 9752759)	$120.70 Special Order
