Maytag JGS8860BDP Parts List

Popular Searches: (Click to search)    assembly  asy  burner  door  dual  gasket  holder  igniter  ignitor  lrg  module  orifice  oven  screw  self  sensor  short  small  spark  tapping


Select a Diagram

01 - Body

02 - Control Panel/top Assembly

03 - Door (ser Pre 10)

04 - Door (ser Pre 11)

05 - Gas Controls

06 - Oven/base

07 - Supplemental Information

08 - Warming Drawer

09 - Wiring Information

Select Diagram ... 01 - Body 02 - Control Panel/top Assembly 03 - Door (ser Pre 10) 04 - Door (ser Pre 11) 05 - Gas Controls 06 - Oven/base 07 - Supplemental Information 08 - Warming Drawer 09 - Wiring Information

02 - Control Panel/top Assembly   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WP5760M339-60	Control Panel/switch Asy (stl) (Series: 10)   (Replaces: 74011685)	$323.30 Special Order
2	74011863	Trim Frame, Drip Pan (Series: 10)	$98.30 Special Order
3	7518P367-60	Grate, Trivet (ctr) (Series: 10)	$170.30 Special Order
4	74011694	Grate (blk) (Series: 10)	$86.10 Special Order
5	3604F426-51	Shield, Control (Series: 10)	$49.10 Special Order
	WP59002061	Screw (6abx3/8-sn) (Series: 10)	$4.80 Special Order
	WP8507P229-60	Control (Series: 10)   (Replaces: 74011798)	$257.70  In-Stock Retail: $251.41
6	WPW10175695	Knob (Series: 10)	$17.20  In-Stock Retail: $16.78
7	3807F738-51	Support, Control Panel (Series: 10)	$26.40 Special Order
	WP90767	Screw (Series: 10)	$4.80  In-Stock Retail: $4.59
8	74011689	Bezel, Knob (dual) (Series: 10)	$48.80 Special Order
9	74011525	Bracket, Control (Series: 10)	$9.20 Special Order
	WP7101P338-60	Screw (8bx3/8-ni) (Series: 10)   (Replaces: 7101P338-60)	$4.40 Special Order
10	W11111008	Screw (10abx1/4p Tr Zn) (Series: 10)   (Replaces: 7101P208-60)	$8.70 Special Order
11	74009538	Screw (Series: 10)	$13.70 Special Order
	74011693	Pan, Drip (dual Burner) (Series: 10)	$21.60 Special Order
12	74009620	Pan, Drip (med) (Series: 10)	$15.40 Special Order
	74009538	Screw (Series: 10)	$13.70 Special Order
13	W10401552	Top Asy (Series: 10)	$247.20 Special Order
14	74010946	Cover, Vent (blk) (Series: 10)	$108.00 Special Order
	7726P396-60	End Cap, Vent (rt-blk) (Series: 10)	$16.20 Special Order
15	7726P396-60	End Cap, Vent (rt-blk) (Series: 10)	$16.20 Special Order
	74010925	End Cap, Vent (lt-blk) (Series: 10)	$7.90 Special Order
16	3601F221-45	Baffle, Vent Cover (Series: 10)	$25.30 Special Order
17	7201P143-60	Gasket (Series: 10)	$13.30 Special Order
18	74011690	Bezel, Knob (smr) (Series: 10)	$97.70 Special Order
19	74011691	Bezel, Knob (Series: 10)	$33.20 Special Order
