Maytag JGD8130ADB Parts List

 View Common Parts for JGD8130ADB

Popular Searches: (Click to search)    4+0  assy  blk  brass  burner  fan  grate  grill  ground  igniter  ignitor  module  rear  relay  seal  spark  switch  top  venturi


Select a Diagram

01 - Blower Plenum

02 - Body

03 - Gas Controls

04 - Top Assembly

05 - Wiring Information

Select Diagram ... 01 - Blower Plenum 02 - Body 03 - Gas Controls 04 - Top Assembly 05 - Wiring Information

Common Parts for JGD8130ADB

Hover over  In-Stock to see individual location availability

Product #	Description	Price / Availability	Add to Cart
74004053	Igniter, Top Burner (Series: 10) View #12 on Diagram	$27.70  In-Stock Retail: $26.97
8215557	Module, Spark (4+0) (Series: 10)   (Replaces: 74004283) View #14 on Diagram	$122.40  In-Stock Retail: $119.35
WP3403M075-10	Burner Assy (blk) (Series: 10)   (Replaces: 74005892) View #13 on Diagram	$92.40  In-Stock Retail: $87.95
W10341820	Switch, Fan (blk) (Series: 10)   (Replaces: 71001564) View #5 on Diagram	$191.80 Special Order
12001452	Relay, Fan (Series: 10)   (Replaces: 71001579) View #15 on Diagram	$131.60  In-Stock Retail: $128.34
WP7538P009-60	Venturi (rear) (Series: 10)   (Replaces: 74005895) View #10 on Diagram	$160.70 Special Order
WP74006073	Ignitor, Ground Assy (Series: 10)   (Replaces: 74006073) View #3 on Diagram	$64.20 Special Order
71003267	Grate, Grill (Series: 10) View #9 on Diagram	$121.80 Special Order
WP74006070	E-burner, Grill (Series: 10) View #1 on Diagram	$218.10 Special Order
WP74005893	Seal (brass) (Series: 10)   (Replaces: 74005893) View #15 on Diagram	$4.80  In-Stock Retail: $4.59
