Maytag JGC8536ADS Parts List

Search Model by Keyword(s):

Popular Searches: (Click to search)    15k  assembly  base  blk  burner  cap  chr  harness  holder  ignitor  knob  lrg  module  orifice  pressure  regulator  screw  small  spark  switch


Select a Diagram


03 - Top Assembly   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item # Part # Description Price / Availability Add to Cart
1 74007737 Grate, Burner (blk-lt) (Series: 10) $80.90
Special Order
74007738 Grate, Burner (blk-rt) (Series: 10) Call for Availability
2 74007739 Grate, Burner (blk-ctr) (Series: 10) $75.60
Special Order
3 WP8284669 WP8284669 Cap, Burner (smr-blk) (Series: 10)
(Replaces: 74007748) 		$41.80
 In-Stock
Retail: $40.76
4 WP74007749 WP74007749 Cap, Burner (med-blk) (Series: 10)
(Replaces: 74007749) 		$51.50
Special Order
5 WP74007750 WP74007750 Cap, Burner (lrg-blk) (Series: 10)
(Replaces: 74007750) 		$75.70
 In-Stock
Retail: $73.83
6 WP74007705 Grommet (Series: 10)   (Replaces: 74007705) $4.50
 In-Stock
Retail: $4.35
7 WP2001F255-E1 WP2001F255-E1 Top, Main (stl) (Series: 10) $236.30
Special Order
8 74007734 74007734 Burner Assembly (small) (Series: 10) $78.10
 In-Stock
Retail: $76.15
WP74009336 WP74009336 Ignitor (Series: 10)
(Replaces: 74009336) 		$23.30
 In-Stock
Retail: $22.66
9 74007735 74007735 Burner Assembly (lrg) (Series: 10) $91.40
 In-Stock
Retail: $89.16
WP74009336 WP74009336 Ignitor (Series: 10)
(Replaces: 74009336) 		$23.30
 In-Stock
Retail: $22.66
10 74007736 74007736 Burner Assembly (x-lrg) (Series: 10) $103.00
 In-Stock
Retail: $100.42
WP74009336 WP74009336 Ignitor (Series: 10)
(Replaces: 74009336) 		$23.30
 In-Stock
Retail: $22.66
11 WP400021-1 WP400021-1 Screw, Burner Base (Series: 10)
(Replaces: 74007714) 		$6.70
 In-Stock
Retail: $6.50
12 WP7733P410-60 WP7733P410-60 Knob, Burner (chr) (Series: 10)
(Replaces: 7733P410-60 74007733) 		$14.90
 In-Stock
Retail: $14.49
13 WP74009336 WP74009336 Ignitor (Series: 10)
(Replaces: 74009336) 		$23.30
 In-Stock
Retail: $22.66
WP8273062 WP8273062 Screw, Ignitor (Series: 10) $4.80
 In-Stock
Retail: $4.59
