Whirlpool GFE461LVT0 Parts List

Popular Searches: (Click to search)    2oz  black  door  hand  hinge  left  lower  oven  paint  pressurized  right  screw  sensor  side  spray  stainless  top  touch  trim  white


Select a Diagram

01 - Cooktop Parts

02 - Control Panel Parts

03 - Chassis Parts

04 - Drawer & Broiler Parts

05 - Door Parts

06 - Optional Parts

Select Diagram ... 01 - Cooktop Parts 02 - Control Panel Parts 03 - Chassis Parts 04 - Drawer & Broiler Parts 05 - Door Parts 06 - Optional Parts

01 - Cooktop Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	9757142	Template,anti-tip (english/spanish)	Call for Availability
	W10252706	Instructions, Installation	Call for Availability
	9757143	Template,anti-tip (english/french)	Call for Availability
	W10200354	Owners Manual	Call for Availability
	W10198585	Tech Sheet	Call for Availability
	9762761	Safer Cooking Tips	Call for Availability
2	WPW10225448	Spring, Locator	$7.60 Special Order
3	WP3196170	Screw	$4.80 Special Order
4	W10651915	Cooktop (black)	$353.80 Special Order
	W10238009	Cooktop (biscuit)	$419.80 Special Order
	W10651914	Cooktop (white)	$364.10 Special Order
5	WP9762851	Warm Zone, 120v	$180.30 Special Order
	W11517959	Element, Surface (3000/1400w - Rf)	$115.00  In-Stock Retail: $112.12
	W10823727	Element, Surface (3000/1900w - Lf)	$213.50  In-Stock Retail: $208.22
	W11171119	Element, Surface (1200 W - Lr & Rr)   (Replaces: WP8273994 8273994)	$182.10  In-Stock Retail: $177.65
6	WP3195060	Hinge, Pin/cooktop	$7.70 Special Order
7	WP3196557	Screw (Replaces: 3196169)	$4.80  In-Stock Retail: $4.59
8	W10170526	Pan, Radiant Elmt	$153.20 Special Order
