Maytag DCF3305BK Parts List

Popular Searches: (Click to search)    4+0  anti  bake  blk  bracket  bulb  burner  door  gasket  hinge  igniter  module  oven  sealed  sensor  short  spark  switch  tip  top


Select a Diagram

01 - Body

02 - Control Panel

03 - Door/drawer

04 - Gas Controls

05 - Oven/base

06 - Top Assembly

07 - Wiring Information

Select Diagram ... 01 - Body 02 - Control Panel 03 - Door/drawer 04 - Gas Controls 05 - Oven/base 06 - Top Assembly 07 - Wiring Information

03 - Door/drawer   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WPW10162384	Gasket, Door (Series: 10) (Replaces: 7201P046-60)	$86.90  In-Stock Retail: $84.70
2	WP74001574	Nut, Snap (round-blk) (Series: 10)	$6.40 Special Order
	74004972	Lining, Oven Door (Series: 10)	$49.00 Special Order
	WP7103P114-60	Nut, Snap (round-wht) (Series: 10)	$6.40 Special Order
	74003643	Nut, Snap (square-blk) (Series: 10)	$4.40 Special Order
3	WP74005546	Spacer, Rubber (Series: 10)	$6.10 Special Order
4	74001842	Insulation, Door (Series: 10)	$25.30 Special Order
5	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.20  In-Stock Retail: $7.99
	3601F353-45	Baffle, Door (Series: 10)	$124.40 Special Order
6	74003320	Glass, Inner (Series: 10)	Call for Availability
7	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.20  In-Stock Retail: $7.99
	74001844	Retainer, Glass (Series: 10)	$4.40 Special Order
8	4870F005-60	Tape, Foil (3`` Wide) (Series: 10)	$4.40 Special Order
9	74006287	Glass, Outer Door (blk) (Series: 10)	$37.80 Special Order
10	74006286	Handle, Door (blk) (Series: 10)	$63.60 Special Order
11	74006394	Screw (Series: 10)	$0.50 Special Order
12	7706P309-60	Frame, Door (blk) (Series: 10)	Call for Availability
13	WP98008545	Screw (1/2``) (Series: 10)	$11.00  In-Stock Retail: $10.67
14	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.20  In-Stock Retail: $7.99
	12001292	Trim, Door Top (blk) (Series: 10)	$39.70 Special Order
15	WP488130	Nut (Series: 10) (Replaces: 7103P082-60)	$4.40  In-Stock Retail: $4.20
	WP74005231	Shaft, Storage Drawer Roller (Series: 10)   (Replaces: 74005231)	Call for Availability
	WP74004078	Roller, Drawer (Series: 10)   (Replaces: 74004078)	$7.00 Special Order
16	74008337	Drawer, Storage (Series: 10) (Replaces: 71003042)	$141.30 Special Order
17	2416F059-78	Panel, Drawer (bsq) (Series: 10)	$50.60 Special Order
18	WP7101P072-60	Screw, Panel (Series: 10)	$4.50 Special Order
19	WPW10131078	Nut, Lock (Series: 10)	$2.40 Special Order
20	WP74005546	Spacer, Rubber (Series: 10)	$6.10 Special Order
21	74003660	Tape, Foil (8.75`` X 1``) (Series: 10)	$4.40 Special Order
22	2404F030-51	Lining, Drawer Panel (Series: 10)	$24.50 Special Order
	74009538	Screw (Series: 10)	$13.00 Special Order
