Whirlpool ED5VHEXVB01 Parts List

Popular Searches: (Click to search)    assembly  cam  closer  complete  control  defrost  door  drier  filter  ice  icemaker  metal  paint  pressurized  service  spray  thermostat  upper  water  white


Select a Diagram

01 - Cabinet Parts

02 - Refrigerator Liner Parts

03 - Refrigerator Shelf Parts

04 - Freezer Liner Parts

05 - Motor And Ice Container Parts

06 - Refrigerator Door Parts

07 - Freezer Door Parts

08 - Dispenser Front Parts

09 - Unit Parts

10 - Air Flow Parts

11 - Control Parts

12 - Icemaker Parts

13 - Optional Parts (not Included)

Select Diagram ... 01 - Cabinet Parts 02 - Refrigerator Liner Parts 03 - Refrigerator Shelf Parts 04 - Freezer Liner Parts 05 - Motor And Ice Container Parts 06 - Refrigerator Door Parts 07 - Freezer Door Parts 08 - Dispenser Front Parts 09 - Unit Parts 10 - Air Flow Parts 11 - Control Parts 12 - Icemaker Parts 13 - Optional Parts (not Included)

07 - Freezer Door Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	LW10153768	Freezer Door (includes Item 8 And Dispenser Front Parts) (black)	$610.10 Special Order
	LW10153769	Freezer Door (includes Item 8 And Dispenser Front Parts) (stainless-vcm)	$610.10 Special Order
	LW10153767	Freezer Door (includes Item 8 And Dispenser Front Parts) (white)	$817.80 Special Order
2	2304413W	Handle (white)	Call for Availability
	WPW10285540	Handle (black)   (Replaces: 2304413B)	$103.10  In-Stock Retail: $100.53
3	WP2182181	Thimble-top	$4.80  In-Stock Retail: $4.59
4	WP489491	Screw (Replaces: 489491)	$4.80 Special Order
5	WP2309718	Trivet (4)	$40.90 Special Order
6	WP3400012	Screw	$4.80 Special Order
7	2159074	Door Gasket, Magnetic (mist Beige)	$210.00 Special Order
	2159082	Door Gasket, Magnetic (black)	$214.40  In-Stock Retail: $209.14
8	WPW10307490	Trim, Door Shelf (Replaces: W10307490)	$12.90 Special Order
9	WP489128	Screw	$6.70 Special Order
10	2311641	Wire Harness	$149.00 Special Order
11	WP2182179	Door Closer, Upper Cam (Replaces: 2182179)	$4.40  In-Stock Retail: $4.20
12	WP489483	Screw	$6.70  In-Stock Retail: $6.51
13	WP2206629B	Bracket, Door Stop (chrome)	$23.40 Special Order
	WP2206629B	Bracket, Door Stop (black)	$23.40 Special Order
14	WP2194705B	Extension, Bottom (black)   (Replaces: 2194705B)	$66.00  In-Stock Retail: $64.34
	WP2194705W	Extension, Bottom (white)	$42.50 Special Order
15	2194707W	Extension, Top (white)	$36.40 Special Order
	2194707B	Extension, Top (black)	$59.30 Special Order
16	WP3400852	Screw	$6.70 Special Order
17	WP2195327	Clip   (Replaces: 2195327)	$4.80 Special Order
18	WP2154473	Connector	$15.30 Special Order
