Maytag CRG7700CAL Parts List

Popular Searches: (Click to search)    baffle  bulb  door  igniter  module  oven  seal  spark  spring  switch


Select a Diagram

01 - Body

02 - Control Panel

03 - Door/drawer

04 - Gas Controls

05 - Oven/base

06 - Wiring Informatin

Select Diagram ... 01 - Body 02 - Control Panel 03 - Door/drawer 04 - Gas Controls 05 - Oven/base 06 - Wiring Informatin

02 - Control Panel   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	74002401	Shield, Vent Deflector (Series: 10)	Call for Availability
2	WP7101P338-60	Screw (8bx3/8-ni) (Series: 10)   (Replaces: 7101P338-60)	$4.40 Special Order
	3801F398-51	Bracket, Panel (rt) (Series: 10)	$25.10 Special Order
	3801F397-51	Bracket, Panel (lt) (Series: 10)	$25.10 Special Order
3	74002404	Pin, Main Top Hinge (Series: 10)	$4.40 Special Order
4	WP98008545	Screw (1/2``) (Series: 10)	$11.60  In-Stock Retail: $11.31
	74002818	Panel, Control (blk) (Series: 10)	Call for Availability
	WPY706189	Screw (8abx3/8-blk) (Series: 10)	$4.80  In-Stock Retail: $4.59
5	74002820	End Cap, Panel (lt-blk) (Series: 10)	Call for Availability
	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.70  In-Stock Retail: $8.47
	74002819	End Cap, Panel (rt-blk) (Series: 10)	Call for Availability
	WPY706189	Screw (8abx3/8-blk) (Series: 10)	$4.80  In-Stock Retail: $4.59
6	7403P309-60	Switch, Rocker (blk) (Series: 10)	$20.60 Special Order
7	WPY706189	Screw (8abx3/8-blk) (Series: 10)	$4.80  In-Stock Retail: $4.59
	12001620	Clock (blk) (Series: 10) (Replaces: 74002007)	Call for Availability
8	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.70  In-Stock Retail: $8.47
	74002448	Shield, Vent (Series: 10)	Call for Availability
9	74002821	Bracket, Clock (Series: 10)	Call for Availability
	WP59002061	Screw (6abx38-zn) (Series: 10)	$4.80 Special Order
10	74005320	Housing, Control Panel (Series: 10)	$10.30 Special Order
	W11233072	Screw (8ab1/2-ni) (Series: 10)	$8.70  In-Stock Retail: $8.47
11		Starter (Series: 10)	Call for Availability
12	3807F406-71	Holder, Lamp (wht) (Series: 10)	Call for Availability
13	74002639	Shield, Control (Series: 10)	$2.50 Special Order
14	74002822	Cover, Light (blk) (Series: 10)	$11.30 Special Order
15	WP95292	Light, Control Panel (Series: 10)	$86.80 Special Order
16	7408P030-60	Receptacle, Snap-in (lt) (Series: 10)	$4.40 Special Order
	7408P029-60	Receptacle, Light (rt) (Series: 10)	$4.40 Special Order
	74002824	Cover, Receptacle Wires (Series: 10)	Call for Availability
17	74002823	Ballast (Series: 10)	Call for Availability
NI	12001323	Harness, Control Panel (Series: 10)	$105.80 Special Order
	74002591	Manual, Use & Care (french) (Series: 10)	Call for Availability
	74002582	Manual, Use & Care (Series: 10)	Call for Availability
	16000329	Guide, Quick Ref. - Magic Chef (Series: 10)	$41.00 Special Order
