1 |
WP486692
|
Speed Nut (Replaces: 486692) |
Call for Availability |
|
2 |
WP1108179
|
 Fan, Blade
(Replaces: 1108179) |
Call for Availability |
|
3 |
2198175
|
Condenser Assembly |
Call for Availability |
|
4 |
WP489464
|
Screw |
Call for Availability |
|
6 |
681390
|
Screw |
Call for Availability |
|
7 |
2256149
|
Heat Shield And Drain Pan |
Call for Availability |
|
12 |
WP2162358
|
 Cover |
Call for Availability |
|
13 |
4387535
|
 Overload (includes Relay) |
Call for Availability |
|
14 |
WP2161324
|
Clip, Defrost Heater |
Call for Availability |
|
15 |
N/A
|
Relay (see Overload) |
Call for Availability |
|
17 |
999509
|
 Capacitor
(Replaces: 2169137) |
Call for Availability |
|
19 |
937252
|
Screw Grommet |
Call for Availability |
|
20 |
2160505
|
Unit Cover, Bottom |
Call for Availability |
|
21 |
489396
|
Clip |
Call for Availability |
|
22 |
WP2188822
|
Evaporator |
Call for Availability |
|
24 |
833697
|
 Motor, Fan
(Replaces: 2162431) |
Call for Availability |
|
25 |
2154114
|
Tray, Evaporator |
Call for Availability |
|
26 |
2176859
|
Harness, Intermediate |
Call for Availability |
|
27 |
W10843121
|
 Drier
(Replaces: 4387019 2164409) |
Call for Availability |
|
28 |
876765
|
 Tube Kit |
Call for Availability |
|
|
W10309990
|
 Compressor (includes Items 12, 13, 15, 17, 27 & 38) (also Order) |
Call for Availability |
|
30 |
2304903
|
Unit Mounting Frame |
Call for Availability |
|
32 |
548695
|
Bracket, Fan Motor |
Call for Availability |
|
33 |
WP2161322
|
 Heater, Defrost |
Call for Availability |
|
34 |
2161330
|
Clip |
Call for Availability |
|
35 |
WPW10225581
|
 Defrost, Bi-metal |
Call for Availability |
|
37 |
876811
|
Screw |
Call for Availability |
|
38 |
WP2172890
|
 Wire Assembly |
Call for Availability |
|
39 |
876811
|
Grommet (4) |
Call for Availability |
|
40 |
489340
|
Screw |
Call for Availability |
|
41 |
W10896764
|
 Baffle, Air |
Call for Availability |
|
42 |
2155547
|
Clip, Heat |
Call for Availability |
|
48 |
2149718
|
Unit Mounting Rail |
Call for Availability |
|
49 |
4159456
|
Screw |
Call for Availability |
|
50 |
1105612
|
Guard, Fan |
Call for Availability |
|
51 |
W11751592
|
Sleeve |
Call for Availability |
|
52 |
WPW10339879
|
 Wire Tie |
Call for Availability |
|
53 |
WP489427
|
 Screw |
Call for Availability |
|
54 |
227991
|
Wire Connector |
Call for Availability |
|
55 |
WP489478
|
 Screw |
Call for Availability |
|
59 |
2208280
|
Clip, Wire & Tube |
Call for Availability |
|
61 |
876764
|
 Valve, Access(3/16``) |
Call for Availability |
|
|
WP978025
|
 Valve, Access (1/4``)
(Replaces: 978025) |
Call for Availability |
|
|
W11693756
|
Screw |
Call for Availability |
|
|
978026
|
 Valve, Access (5/16``) |
Call for Availability |
|
|
978027
|
 Valve, Access (3/8``) |
Call for Availability |
|
|
978028
|
 Valve, Access (1/2) |
Call for Availability |
|
|
978029
|
Valve Access (5/8``) |
Call for Availability |
|
|
978030
|
Valve, Access (3/4``) |
Call for Availability |
