Whirlpool DU945PWKT1 Parts List

Popular Searches: (Click to search)    adhesive  black  deflector  fuse  gasket  includes  item  latch  lid  limit  paint  spray  spring  switch  thermal  thermostat  tine  tips  touch  white


Select a Diagram

01 - Frame And Console, Literature

02 - Inner Door

03 - Tub Assembly

04 - Pump And Motor

05 - Upper Dishrack And Water Feed

06 - Lower Dishrack

07 - Miscellaneous

Select Diagram ... 01 - Frame And Console, Literature 02 - Inner Door 03 - Tub Assembly 04 - Pump And Motor 05 - Upper Dishrack And Water Feed 06 - Lower Dishrack 07 - Miscellaneous

01 - Frame And Console, Literature   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	LIT8275370	Literature Parts (tech Sheet) (guide, Energy)	Call for Availability
	LIT3385181	Literature Parts (instructions, Installation)	Call for Availability
	LIT3367007	Literature Parts (instructions, Installation (supplement) (locating Your Water Supply))	Call for Availability
	LIT3381180	Literature Parts (guide, Use & Care)	Call for Availability
	LIT8528833	Literature Parts (tech Sheet) (english)	Call for Availability
	LIT8528834	Literature Parts (tech Sheet) (french)	Call for Availability
3	WP8530929	Control, Electronic	$159.20 Special Order
4	675813	Fuse, Thermal (Replaces: 3376359)	$33.40  In-Stock Retail: $32.55
6	8275206	Console (includes Insert & Active Overlay) (black)	$147.50 Special Order
	8275207	Console (includes Insert & Active Overlay) (white)	$149.50 Special Order
	8275208	Console (includes Insert & Active Overlay) (biscuit)	$156.60 Special Order
8	WP9743028	Door Frame (black)	$89.80 Special Order
9	WP3380854	Bolt, Latch (Replaces: 3380854)	$60.20  In-Stock Retail: $58.64
10	WP3369457	Lever, Latch White (Replaces: 3372231)	Call for Availability
	3375062	Lever, Latch (biscuit)	Call for Availability
	WP3369457	Lever, Latch (black) (Replaces: 3369457)	Call for Availability
11	4318273	Switch, (2) (Replaces: WP4318273 3369325)	Call for Availability
12	WP3368955	Pin, Switch (2)   (Replaces: 3368955)	Call for Availability
13	8275394	Harness And Protector	Call for Availability
14	3376405	Elbow, Harness	$9.90 Special Order
15	WP3400892	Screw	$4.80 Special Order
16	8051304	Cover, Timer	$37.90 Special Order
17	WP3374501	Motor, Dual (Replaces: 3374501)	Call for Availability
19	8054178	Panel, Front (biscuit)	$89.00 Special Order
	WP3379376	Panel Front (white)   (Replaces: 3379376)	$107.00 Special Order
	WP3379375	Panel Front (black)	Call for Availability
22	675782	Spring, Door Catch	$4.80 Special Order
23	675782	Catch, Door	$4.80 Special Order
26	WP3373234	Bearing Spring (2)   (Replaces: 3373234)	$6.50  In-Stock Retail: $6.30
