Whirlpool DU806CWDB5 Parts List

Popular Searches: (Click to search)    and  assembly  black  breakdown  dispenser  for  gasket  latch  lid  motor  page  paint  parts  pump  refer  screw  seal  touch  valve  white


Select a Diagram

01 - Frame And Console

02 - Inner Door

03 - Tub Assembly

04 - Pump And Sprayarm

05 - Pump And Motor

06 - Dishrack

07 - Miscellaneous, Lit/optional

Select Diagram ... 01 - Frame And Console 02 - Inner Door 03 - Tub Assembly 04 - Pump And Sprayarm 05 - Pump And Motor 06 - Dishrack 07 - Miscellaneous, Lit/optional

03 - Tub Assembly   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	3375133	Tub Assembly	$70.30 Special Order
2	3380371	Tub, Wheel Assembly (8)	$13.30 Special Order
3	3368933	Runner (2)	$14.80 Special Order
4	8193716	Leveler (2) (Replaces: 3376439)	$56.00  In-Stock Retail: $54.61
5	3370389	Screw, Shoulder	$4.40 Special Order
6	WP302819	Wheel (2) (Replaces: 302819)	$4.80 Special Order
7	WP681414	Screw,	$4.80 Special Order
8	3374719	Plate, Latch	$15.80 Special Order
9	WP3374720	Screw	$45.70 Special Order
10	WPW10509257	Gasket (Replaces: W10082795 3376927)	$59.90  In-Stock Retail: $58.41
11	WP3369322	Grate	$58.90 Special Order
12	WP8528862	Deflector (2)	$61.50  In-Stock Retail: $59.94
13	WPW10082894	Heater (includes Item 14)	$90.90 Special Order
14	WP717273	Washer, Rubber (2)	$4.80  In-Stock Retail: $4.59
15	3378706	Nut (2) (heater Terminal)	$4.40 Special Order
16	W10844024	Water Valve (Replaces: 3379356 8283346 WPW10219643 3378779)	$60.10  In-Stock Retail: $58.58
17	WP489069	Screw	$4.80 Special Order
18	8194496	Check, Valve Assembly	$32.00 Special Order
19	3369180	Hose, Coupler	$4.40 Special Order
20	3379740	Support, Heater (3)	$38.40 Special Order
21	WP596669	Clamp	$4.80  In-Stock Retail: $4.59
22	371499	Clamp	$9.10 Special Order
23	WP489128	Screw	$6.70 Special Order
24	W10102260	Relay	$92.80 Special Order
25	WP304231	Screw,	$4.80 Special Order
26	WP3368928	Fuse, Thermal   (Replaces: 3368928)	$47.00  In-Stock Retail: $45.79
28	WP3373228	Spring, Door (2)	$20.80  In-Stock Retail: $20.21
29	3369048	Housing, Float Switch	$32.40 Special Order
30	WPW10102498	Switch, Float (Replaces: 3369067)	$40.90 Special Order
31	3369049	Cover, Switch Housing	$12.10 Special Order
32	WP8519552	Float	$76.50 Special Order
33	717488	Nut	$8.20 Special Order
34	WP3379921	Toe, Panel (white)	$95.10  In-Stock Retail: $92.78
	WP3379920	Toe, Panel (black) (Replaces: 3371968 3375423 3368942)	$105.30 Special Order
35	3373186	Panel, Access (designer White Model)	Call for Availability
	WP3374730	Panel, Access (black Model (with Clip Assembly))	$89.50  In-Stock Retail: $89.45
36	WP302868	Screw   (Replaces: 302868)	$4.80  In-Stock Retail: $4.59
37	WP304669	Hose, Inlet	$35.50 Special Order
38	WP3374077	Hose, Drain (Replaces: 3368781)	$83.90  In-Stock Retail: $81.82
39	WP3378123	Clip, Grounding	$0.70 Special Order
40	W11086533	Shield, Sound	$22.90 Special Order
45	3371881	Nut	Call for Availability
46	WP3374728	Extension & Clip Assembly, Designer White Model	Call for Availability
48	WP681414	Screw	$4.80 Special Order
50	3371542	Power Cord	$119.00 Special Order
51	WP356138	Clamp, Hose (Replaces: 356138)	$4.80 Special Order
52	W11693756	Screw	$8.70 Special Order
