GE GFE29HSDASS Parts List

Popular Searches: (Click to search)    aasm  asm  condenser  def  defrost  fan  filt  heater  icon  led  motor  pcb  refrigeration  sensor  side  temperature  thermostat  valve  water  wr87x10211


Select a Diagram

10 - Case Parts

1 - Dispenser Door

2 - Machine Compartment

3 - Freezer Door

4 - Fresh Food Door - Rh

5 - Freezer Section

6 - Freezer Shelves

7 - Ice Maker & Dispenser

8 - Fresh Food Section

9 - Fresh Food Shelves

Select Diagram ... 10 - Case Parts 1 - Dispenser Door 2 - Machine Compartment 3 - Freezer Door 4 - Fresh Food Door - Rh 5 - Freezer Section 6 - Freezer Shelves 7 - Ice Maker & Dispenser 8 - Fresh Food Section 9 - Fresh Food Shelves

4 - Fresh Food Door - Rh   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
89	WR01X11044	Scr 10-32 B Rns .353 S	$10.50 Special Order
114	WR01X11007	Fastener Door Handle	$10.50  In-Stock Retail: $10.22
115	WR01X11014	Set Screw	$10.50 Special Order
135	WR14X10366	Gasket Ff	$126.40 Special Order
136	NLA ITEM	Arc Handle Asm Ff	Call for Availability
149	WR01X10196	Screw 8-18 Hi/lo 5/8	$10.50  In-Stock Retail: $10.22
232	WR78X12856	Door Foam Asm Ff Rh	Call for Availability
237	WR01X11032	Scr 10-24 Ab Rnt 20 5/8	$10.50 Special Order
238	WR02X13634	Stop Door Rh/lh Asm	$17.80 Special Order
239	WR04X10181	Badge Ge Asm	$13.10 Special Order
242	WR17X13086	Divider Gallon Bin	$55.30 Special Order
243	WR71X11052	Bin Gal Rh Ff Asm	$68.80 Special Order
244	WR11X23035	Closure Door Asm Rh	$67.20 Special Order
246	WR71X11063	Bin Dairy Rh Ff Door	$81.70 Special Order
247	WR71X11050	Bin Cond Rh Ff Asm	$61.70 Special Order
248	WR71X11063	Bin Dairy Rh Ff Base	$81.70 Special Order
249	NLA ITEM	Bin Dairy Rh Ff Asm	Call for Availability
