Maytag JGRP436WP01 Parts List

Popular Searches: (Click to search)    adhesive  blade  electrode  fan  gas  hinge  jack  left  meat  module  orifice  polish  probe  receiver  reginitor  sealer  sensor  silastic  spark  steel


Select a Diagram

01 - Cooktop, Burner And Grate Parts

02 - Burner Box, Gas Valves, And Switches

03 - Chassis Parts

04 - Venting Parts

05 - Oven Parts

06 - Oven Door Parts

07 - Internal Oven Parts

08 - Optional Parts

Select Diagram ... 01 - Cooktop, Burner And Grate Parts 02 - Burner Box, Gas Valves, And Switches 03 - Chassis Parts 04 - Venting Parts 05 - Oven Parts 06 - Oven Door Parts 07 - Internal Oven Parts 08 - Optional Parts

01 - Cooktop, Burner And Grate Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	W10403308	Tech Sheet (english)	Call for Availability
	W10403309	Tech Sheet (french)	Call for Availability
	W10399389	Use & Care Guide	Call for Availability
	W10394575	Installation Instructions	Call for Availability
	9762761	Safer Cooking Tips (english)	Call for Availability
	W10065852	Safer Cooking Tips (french)	Call for Availability
	W10075750	Instr, Installer	Call for Availability
	W10340424	Orifice (lf,rf (inner))	$56.20 Special Order
2	W10819958	Orifice (lf,rf (outer))   (Replaces: W10256132)	$56.10 Special Order
	W10791075	Orifice (cr) (Replaces: W10282663)	$62.20 Special Order
	W11051480	Orifice (lr,cf,rr)	$53.10 Special Order
3	WPW10364555	Orifice Holder (lf,rf)   (Replaces: W10364555)	$68.10 Special Order
4	WPW10364556	Orifice Holder (lr,cf,rr)   (Replaces: W10364556)	$61.40 Special Order
	W10282659	Orifice Holder (cr)	$25.20  In-Stock Retail: $24.52
5	W11344501	Grate, Burner	$105.20 Special Order
6	W10323249	Trim, Island	$153.70 Special Order
8	W10185266	Pad, Grate	$8.90  In-Stock Retail: $8.62
9	W10276494	Bezel	$50.00 Special Order
10	W10271524	T-strip	$131.80 Special Order
11	W10323250	Island, Trim Insert	$88.00 Special Order
12	WPW10464535	Assembly, Keypad   (Replaces: W10344181)	$799.50  In-Stock Retail: $799.49
13	WPW10256034	Cap, Burner (rf,lf)	$82.90 Special Order
	WPW10364463	Cap, Burner (cr)   (Replaces: W10364463)	$33.50  In-Stock Retail: $32.68
	WPW10256032	Cap, Burner (rr,cf,lr)	$53.00  In-Stock Retail: $51.70
14	W11106799	Base, Burner (rf,lf) (Replaces: WPW10495853 W10256029)	$78.50 Special Order
	WPW10256027	Base, Burner (rr,cf,lr)	$60.60 Special Order
	WPW10282515	Base, Burner (cr) (Replaces: W10282515)	$89.90  In-Stock Retail: $87.67
15	W10256046	Spring, Electrode (lf,lr,rf,rr,cf)	$7.50 Special Order
	8286863	Spring, Electrode (cr)	$47.80 Special Order
16	W10833887	Electrode (lf,rf,rr,cf,lr)   (Replaces: W10256047)	$28.90  In-Stock Retail: $28.19
	WPW10145991	Electrode (cr)	$50.70 Special Order
17	WPW10145531	Assembly, Power Supply   (Replaces: W10145531)	$189.60 Special Order
18	W10352966	Cooktop (middle)	$192.70 Special Order
	W10352969	Cooktop (left)	$193.20 Special Order
	W10352967	Cooktop (right)	$193.00  In-Stock Retail: $188.28
21	W10854967	Electrode, Wire (Replaces: 8286725)	$26.40 Special Order
23	W11444940	Panel, Control	$390.10 Special Order
24	W10145568	Knob, Control Rf,lf	$32.90 Special Order
28	W10145454	Knob, Control	$28.20 Special Order
29	3400099	Screw	$35.30 Special Order
33	WP7101P338-60	Screw   (Replaces: 7101P338-60)	$4.40 Special Order
35	WP74003976	Screw	$4.60 Special Order
36	W10130760	Bracket,console (left)	$45.00 Special Order
	W10130759	Bracket,console (right)	$45.00 Special Order
