Whirlpool WTW5550XW2 Parts List

Popular Searches: (Click to search)    actuator  assembly  belt  capacitor  drain  drive  hoses  latch  lid  lock  motor  paint  pressurized  pulley  pump  run  shift  spray  touch  white


Select a Diagram

01 - Top And Cabinet Parts

02 - Console And Dispenser Parts

03 - Basket And Tub Parts

04 - Gearcase, Motor And Pump Parts

05 - Optional Parts (not Included)

Select Diagram ... 01 - Top And Cabinet Parts 02 - Console And Dispenser Parts 03 - Basket And Tub Parts 04 - Gearcase, Motor And Pump Parts 05 - Optional Parts (not Included)

02 - Console And Dispenser Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WPW10269604	Console	$276.30 Special Order
2	WPW10251392	Knob, Control (includes Item 24)	$37.00 Special Order
3	WPW10269602	User Interface	$208.50  In-Stock Retail: $203.36
4	W10853898	Screw, 8-16 X 3/4	$4.80 Special Order
5	WP8312709	Clip, Console   (Replaces: 8312709)	$12.50  In-Stock Retail: $12.12
6	W10480104	Control Unit Assembly, Machine & Motor	$196.50 Special Order
7	W10420984	Panel, Console Rear Cover	$190.70 Special Order
8	WP488729	Screw, 8-18 X 1/2	$4.80  In-Stock Retail: $4.59
9	WP489069	Screw, 8-18 X 3/8	$4.80 Special Order
10	W10280079	Seal, Console	$48.00 Special Order
11	WPW10525195	Cord, Power	$86.40 Special Order
12	W10846509	Screw, Power Cord Ground	$4.80 Special Order
13	W11158805	Housing Assembly - Dispenser	$216.00  In-Stock Retail: $210.64
14	W11168740	Valve, Cold Water Inlet (Replaces: WPW10240949 W10240949)	$140.30  In-Stock Retail: $136.84
15	W11168743	Valve, Hot Water Inlet (Replaces: WPW10240948 W10240948)	$126.40  In-Stock Retail: $123.27
16	W10240967	Harness, Valve	$107.40 Special Order
17	W11700520	Screw, Dispenser Housing Mounting	$8.70 Special Order
18	WPW10109200	Screw, Inlet Valve Mounting	$4.80  In-Stock Retail: $4.59
19	W10240946	Bezel, Dispenser	$18.60 Special Order
20	WPW10658443	Drawer, Dispenser Assembly	$63.30 Special Order
21	W10274524	Tensioner, Facia	$9.90 Special Order
22	WP9740848	Screw, 8-18 X 1/2	$4.80 Special Order
23	W10325119	Spacer, Knob	$11.70 Special Order
24	WP8536939	Clip, Knob (Replaces: 8536939)	$4.80  In-Stock Retail: $4.59
25	WPW10287476	Facia, Dispenser	$37.90 Special Order
26	W11213336	Nut, U Type   (Replaces: W10298336)	$4.60 Special Order
27	W10323092	Seal, Ui	$45.30 Special Order
28	W10285493	Cable, Ui	$65.70 Special Order
