Whirlpool KUDE40FXPA3 Parts List

Search Model by Keyword(s):

Popular Searches: (Click to search)    2oz  adjuster  assembly  black  bracket  cable  door  drain  hose  includes  latch  metal  paint  pressurized  pump  spray  switch  touch  undercounter  white


Select a Diagram


01 - Door And Panel Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item # Part # Description Price / Availability Add to Cart
1 W10195614 Tech Sheet/french Call for Availability
W10321621 Instructions, Installation Call for Availability
W10395349 Energy Guide Call for Availability
W10300929 Guide, Use & Care (english/french) Call for Availability
W10300597 Guide, Use & Care (spanish Custom) Call for Availability
W10195613 Tech Sheet/english Call for Availability
2 W11612302 Arm, Hinge (left) $97.20
 In-Stock
Retail: $94.81
WP8534853 WP8534853 Arm, Hinge (right)
(Replaces: 8534853)
$159.90
 In-Stock
Retail: $155.99
3 W10850371 Vapor Barrier Assembly   (Replaces: W10321449) $20.50
 In-Stock
Retail: $19.98
4 W10234565 Insulation Front Panel $41.10
Special Order
5 WPW10441006 Access Panel (black) $96.10
 In-Stock
Retail: $93.68
6 WPW10292632 Front Panel, Panel Ready (black) $176.10
Special Order
7 WPW10637074 WPW10637074 Misc. Hardware $56.10
Special Order
8 W10827631 Toe Panel (includes Item 9) (black)   (Replaces: WPW10369024 W10369024) $96.60
 In-Stock
Retail: $94.17
9 W10831329 W10831329 Insulation Toe Panel $23.60
Special Order
10 WP3400071 Screw $4.80
Special Order
11 WPW10503548 WPW10503548 Screw (black)
(Replaces: W10331789)
$16.00
 In-Stock
Retail: $15.58
12 WP489069 WP489069 Screw $4.80
Special Order
13 W11116870 Bracket, Panel Control   (Replaces: W10194911) $48.50
Special Order
14 WPW10366978 Seal, Panel Ready $15.90
Special Order
