GE DPXH46GA0CC Parts List

Popular Searches: (Click to search) asm basket belt coil dome door drum dryer gas glide handle ignitor kit lower plug seal secondary valve

Select a Diagram

1 - Controls & Top Panel

2 - Front Panel & Door

3 - Cabinet & Drum

4 - Motor

5 - Burner

Double click the image below to zoom-in

Hover over In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability
1	49-9963-2	Install/owners Guide	Call for Availability
	31-15415	Mini Manual	Call for Availability
	49-90380	Use&care Inst Manual	Call for Availability
	NLA ITEM	Stacking Kit	Call for Availability
7	WE02X10009	Clip-top Front/panel	$32.30 Special Order
11	WE13X10017	Bracket - Control Board	$19.00 Special Order
12	NLA ITEM	Control Board/sensor	Call for Availability
13	WE04X10135	Switch - Temp/start (Replaces: WE04X10062)	$54.40 Special Order
14	WH12X10058	Switch X-tra Rinse/temp	$87.60 Special Order
15	NLA ITEM	Switch Start	Call for Availability
17	WE13X10018	Bracket Control	$22.40 Special Order
23	WE08X10013	Harness-gas W/belt Sw	$221.40 Special Order
27	WE20X10031	Control Panel Asm	$188.20 Special Order
	WE20X10030	Control Panel Asm.	$242.40 Special Order
29	NLA ITEM	Knob - Rotary Cc (Replaces: WE01X10086)	Call for Availability
	NLA ITEM	Knob - Rotary Wh (Replaces: WE01X10084)	Call for Availability
31	NLA ITEM	Knob Asm - Timer Wh (Replaces: WE01X10085)	Call for Availability
	NLA ITEM	Knob Asm - Timer Cc (Replaces: WE01X10087)	Call for Availability
38	WE04X10063	Beeper	$156.30 Special Order
100	NLA ITEM	Timer - Dryer	Call for Availability
224	WE04X10011	Panel Top Wh	Call for Availability
	WE20X10032	Panel Top Cc	$156.30 Special Order
1111	NLA ITEM	Screw 8-32 X .250	Call for Availability
