Hover over In-Stock to see individual location availability
| Item # | Part # | Description | Price / Availability | Add to Cart | |
|---|---|---|---|---|---|
| 1 | Back,main | $91.50 |
|||
| 2 | Shield,wire ,lock Motor | $17.20 |
|||
| 3 | Panel,body Side ,white ,(2) | $89.60 |
|||
| 5 |
 Screw-leveling |
$11.80 |
|||
| 6 | Rack,oven | $111.30 |
|||
| 9 |
 Pan,broileroptional Access0ry (Replaces: 316081900) |
Call for Availability | |||
| 10 |
Insert,broiler Panoptional Accessory (Replaces: 316082000) |
Call for Availability | |||
| F12 |
 Switch,light (Replaces: 318089913) |
$65.10 |
|||
| 14 |
 Receptacle,oven Light |
$42.60 |
|||
| 15 |
 Bulb/lamp,light (Replaces: 5303013071) |
$11.87 Retail: $13.49 |
|||
| 16 | Lens,oven Light ,glass (Replaces: 318406100 08011086) | $9.30 |
|||
| 17 |
 Retainer,light Cover |
Call for Availability | |||
| 29 | Bumper,(2) | $12.90 |
|||
| F37 |
 Probe,oven Temp |
$44.60 Retail: $43.49 |
|||
| F39 | Cord,electric | $35.90 |
|||
| 41 | Cover-hinge Cutout | $57.70 |
|||
| 54 |
 Housing,oven Light |
$42.10 Retail: $41.06 |
|||
| 58A | Insulation,oven Wrapper | $81.50 |
|||
| 58B | Insulation,rear & Bottom ,oven Wrapper | $22.70 |
|||
| 59 | Duct,oven Vent | $25.00 |
|||
| 62 |
 Terminal Block Kit (Replaces: 5303935061) |
$8.20 Retail: $7.99 |
|||
| 66 |
 Element,broil ,2750w (Replaces: 318255600) |
$139.40 |
|||
| F67 |
 Element,bake ,3000w (Replaces: 318255002) |
$162.50 Retail: $158.49 |
|||
| 68 | Support,hanger ,(2) ,broil Element | $22.60 |
|||
| 70 | Shield,insulation ,right ,(2) | $18.60 |
|||
| 70A | Shield,insulation ,left ,(2) | $18.60 |
|||
| 71 | Panel,cover | $29.60 |
|||
| 74 | Bumper,bodyside | Call for Availability | |||
| 76 | Front,oven | $95.70 |
|||
| 80 |
 Plate,oven Mtg |
$37.50 |
|||
| 81 |
 Spring,oven |
$214.60 |
|||
| 82 | Shield,insulation ,lower | $57.80 |
|||
| 83 | Liner,oven Assy | $202.30 |
|||
| 86 |
 Receptacle,hinge |
Call for Availability | |||
| F89 |
 Motor,latch Assy |
$99.10 |
|||
| 127 |
 Adapter Assembly,vent Tube ,w/converter |
$54.40 |
|||
| 143 | Support,wire | $2.10 |
|||
| 152 | Bracket,lateral Panel ,(4) | $5.80 |
|||
| 165 | Plate,shield | $1.60 |
|||
| 166 | Bracket,base Support ,(2) | $51.30 |
|||
| F166 | Bracket,base Support ,(2) | $41.10 |
|||
| 177 | Gasket,vent | $20.80 |
|||
| 178 | Bracket,vent Tube | $10.80 |
|||
| 200 | Frame,drawer ,black ,front ,w/rollers | $46.80 |
|||
| 201 | Frame,drawer ,rear | $37.20 |
|||
| 242 | Trim,center ,black | $29.90 |
|||
| NI | Nut-10-32 | $8.20 |
|||
| Screw,8-18 X 1/2,black | $9.80 Retail: $9.49 |
||||
| Harness,wiring ,door Switch | $27.20 |
||||
| Harness,wiring ,lock Motor | $20.40 |
||||
| Screw,8 X 0.750 | $10.30 |
||||
| Harness,wiring ,main | $74.80 |
||||
| Screw,8 X 0.500 | $10.30 |
||||
| Screw,shoulder Head ,8-18 X 1/2 | $5.30 |
||||
| Screw,10-24 X 0.906 | $9.80 |
||||
| Screw,8-18 X 0.406 | $9.80 |
||||
