GE JTP18BA2BB Parts List

Popular Searches: (Click to search)    3400w  asm  bake  broil  element  fan  hinge  holder  kit  lamp  lock  motor  oven  pack  screw  sensor  support  window


Select a Diagram

1 - Control Panel

2 - Body Parts

3 - Door

4 - Door Lock

5 - Fan

Select Diagram ... 1 - Control Panel 2 - Body Parts 3 - Door 4 - Door Lock 5 - Fan

1 - Control Panel   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WB36T10197	Panel Cntl Asm	Call for Availability
3	WB34K5237	Control Panel Shield	$50.70 Special Order
16	NLA ITEM	Ovn Cntl (erc3-h)   (Replaces: WB27T10069)	Call for Availability
32	WB26K5061	Fan Asm	$172.90  In-Stock Retail: $168.60
	WB26K5069	Motor Fan (Replaces: WB26T10006)	$248.30 Special Order
108	WB1X5364	Screw (cr)	$10.50  In-Stock Retail: $10.22
158	NLA ITEM	Switch Limit	Call for Availability
159	NLA ITEM	Switch Limit	Call for Availability
205	WB6K5041	Fan Housing Screen	$49.50 Special Order
216	WB34K5216	Top Wire Cover	$28.40 Special Order
227	WB2K5387	Top Insulation Retainer	Call for Availability
264	WB07T10165	Trim Vnt Inr (blk)	$42.20 Special Order
416	WB34K5217	Fan Housing Cover	$38.70 Special Order
513	WB26K5063	Fan Housing	$38.60 Special Order
595	WB2K5126	Conduit Clamp	$11.60 Special Order
600	WB18K5473	Conduit Wire Asm	$32.60 Special Order
699	WB1M1	Screw St10-16 X 7/16"	$10.10  In-Stock Retail: $9.83
761	WB1K5029	Screw-black	$10.50 Special Order
813	WB1X1261	Screw	$10.50 Special Order
847	WB1X1118	Screw-black	$10.50 Special Order
	NLA ITEM	Screw-black	Call for Availability
862	WB1X1178	Screw	$24.20 Special Order
875	WH2X930	Screw 8-18 Ab Hxw 3/8	$10.50 Special Order
926	WB1X1260	Ground Washer	$9.30 Special Order
941	WB1X1399	Lockwasher	Call for Availability
999	31-10125	Installation Instruction	Call for Availability
	31-13647	Manual Mini & Wd Asm	Call for Availability
	49-8443	Pm Cookbook	Call for Availability
	49-8908	Manual Use & Care	Call for Availability
	WB18K5490	Door Switch Wire Harness	$38.20 Special Order
	WB18K5491	Lock Motor Wire Harness	$10.40 Special Order
	WB18T10108	Harness Wire Main	$75.30 Special Order
	WB18T10109	Harness Wire F.o.d.	Call for Availability
