Maytag A8RXNGMWE01 Parts List

Popular Searches: (Click to search)    [customer  adaptive  assembly  brush  complete  control  defrost  drier  fan  icemaker  kit  material  service  silicone  single  solenoid  touch  valve  washer  white


Select a Diagram

01 - Cabinet Parts

02 - Door Parts

03 - Liner Parts

04 - Unit Parts

05 - Icemaker Parts

06 - Shelf Parts

07 - Optional Parts

Select Diagram ... 01 - Cabinet Parts 02 - Door Parts 03 - Liner Parts 04 - Unit Parts 05 - Icemaker Parts 06 - Shelf Parts 07 - Optional Parts

04 - Unit Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WPW10222450	Support Plate, Compressor	$91.10 Special Order
2	WP489442	Screw (Replaces: 489442)	$6.70 Special Order
3	WP2264004	Condenser	$129.10 Special Order
4	WP2263749	Heater, Defrost	$61.70  In-Stock Retail: $60.13
5	2264835	Clip, Condenser	$10.70 Special Order
6	WPW10171469	Screw	$6.70 Special Order
7	2319224	Heat Shield	$81.10 Special Order
8	WP2263929	Air Baffle	$56.80 Special Order
9	W11578915	Motor, Condenser   (Replaces: WP2188875 W10854034 2188875)	$68.90  In-Stock Retail: $67.18
10	WPW10169124	Grommet (service)	$4.80 Special Order
11	W10812038	Clip, Wire	$6.30 Special Order
12	WPW10475495	Roller (Replaces: 2150304)	$19.60  In-Stock Retail: $19.05
13	WP2264756	Axle, Rivet	$4.80  In-Stock Retail: $4.59
14	8201619	Wedge-evaporator	$95.00 Special Order
15	WP2263920	Evaporator Assy.   (Replaces: 2263920)	$207.60 Special Order
16	W10805623	Start Device, Combination (start Relay And Overload) (service)	$75.30 Special Order
17	WPW10339879	Strap	$4.80 Special Order
18	2264838	Sleeve	$55.00 Special Order
19	2212996	Bale Strap	$7.90 Special Order
20	2264278	Tube, Drain	$49.60 Special Order
21	2266467	Clip, Harness	$28.90 Special Order
22	24364001	Clip, Compressor	$4.40 Special Order
23	8201619	Wedge, Evaporator	$95.00 Special Order
24	2264129	Fan Blade	$61.00  In-Stock Retail: $59.51
25	WP489489	Screw	$4.50 Special Order
26	2266360	Shield, Electrical	$9.40 Special Order
27	WPW10151677	Wire Assy. Unit	$82.10 Special Order
28	W10285060	Compressor (includes Items 10, 16, 29 & 30) (also Order 482801 Installation Kit & 876765 Tube Kit)	$243.10 Special Order
29	WPW10143759	Drier (service) (Replaces: W10143759)	$17.10  In-Stock Retail: $16.59
	W10843121	Drier (production)	$31.80  In-Stock Retail: $30.99
30	WPW10662129	Capacitator (production) (Replaces: 2169373 2264017)	$47.60  In-Stock Retail: $46.35
	WPW10662129	Capacitator (service) (Replaces: 2169373)	$47.60  In-Stock Retail: $46.35
31	2264131	Extension, Tube-heat	$10.30 Special Order
32	WP2263928	Evaporating Tray	$92.50 Special Order
33	W10289687	Tube, Discharge (incl. Pre-cooler)	$76.80 Special Order
34	W11676464	Tube, Process	$58.20 Special Order
NI	WP978025	Valve, Access (1/4``) (Replaces: 978025)	$61.40  In-Stock Retail: $59.82
	978026	Valve, Access (5/16``)	$73.50  In-Stock Retail: $71.65
	978027	Valve, Access(3/8``)	$75.00  In-Stock Retail: $73.08
	978028	Valve, Access (1/2``)	Call for Availability
	978029	Valve, Access (5/8``)	$65.50 Special Order
	978030	Valve, Access (3/4``)	$78.60 Special Order
	876764	Valve, Access(3/16``)	$56.70  In-Stock Retail: $55.29
	N/P	Refrigerant Charge (3.75 Ozs. (r134a))	Call for Availability
