GE DJXR433EG0WW Parts List

Popular Searches: (Click to search)    and  asm  bearing  clip  door  drum  filter  idler  knob  limit  motor  pulley  sleeve  slide  start  switch  t'stat  timer  top  white


Select a Diagram

1 - Backsplash, Blower & Motor

2 - Front Panel & Door

3 - Cabinet

4 - Drum

Select Diagram ... 1 - Backsplash, Blower & Motor 2 - Front Panel & Door 3 - Cabinet 4 - Drum

1 - Backsplash, Blower & Motor   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	31-16135	Install Instruction	Call for Availability
	49-90299	Use & Care Manual	Call for Availability
	31-16093	Mini Manual	Call for Availability
3	WE49X22294	End Cap Lh Wh	$62.60 Special Order
4	WE19X20467	End Cap Rh Wh   (Replaces: WE19M1473)	$17.10 Special Order
7	WE1M654	Timer Knob Asm Wh	$25.70  In-Stock Retail: $41.37
13	WE19M1493	Back. Asm	$185.10  In-Stock Retail: $220.32
19	WE01X20378	Knob And Clip Asm (Replaces: WH01X10460 WH01X10307)	$20.50  In-Stock Retail: $26.11
35	WE4M519	Start Switch (Replaces: WE4M402 WE4M326)	$13.40  In-Stock Retail: $22.58
41	WH01X10106	U Clip (Replaces: WE1X980)	$10.00 Special Order
72	WE19M1481	Rear Panel	$62.90 Special Order
75	WE2M173	Screw	$10.50 Special Order
80	WE4M255	Resistor 4500 Ohm (Replaces: WE04X10029)	$28.00  In-Stock Retail: $27.95
87	WE4M411	Rotary Switch 4 Temp (Replaces: WE4M373)	$68.20 Special Order
100	NLA ITEM	Timer Metal Shaft	Call for Availability
199	WE2M98	Screw	$10.50 Special Order
200	WE1X688	Clamp (Replaces: WE00M111)	$21.10 Special Order
	WE1X688	Clamp (Replaces: WE00M112)	$21.10 Special Order
201	WE16M15	Blower Wheel	$58.20  In-Stock Retail: $75.00
203	WE13X200	Strap Motor	$10.50 Special Order
204	WE1X921	Strap Motor	$41.50 Special Order
205	WE13M39	Motor Support	$39.00  In-Stock Retail: $38.02
213	WE03X29897	Belt Drive   (Replaces: WE12M29 WE12M22)	$33.20  In-Stock Retail: $53.72
215	WE03X20434	Idler Arm	$85.80  In-Stock Retail: $83.69
216	WE12X83	Pulley Idler (Replaces: WE12M8)	$15.40  In-Stock Retail: $34.94
218	WE1M473	Gasket Seal, Hsng Exh	$3.70 Special Order
	WE14M93	Blower Housing	$31.00 Special Order
228	WE14X20421	Pipe Exaust	$29.20 Special Order
230	WE4M216	T'stat Bias Drum Out	$100.30  In-Stock Retail: $97.77
231	WD02X10057	Screw	$10.50  In-Stock Retail: $10.22
232	WE2M202	Screw	$10.50 Special Order
233	WE13X20394	Motor Plate (e-coat) (Replaces: WE13M35)	$26.60  In-Stock Retail: $25.95
234	WE2M96	Cap Nut	$10.10 Special Order
235	WE1M280	Screw	$10.50 Special Order
237	WD02X10057	Screw (Replaces: WE2M154)	$10.50  In-Stock Retail: $10.22
239	WR2X9260	Screw	$25.10  In-Stock Retail: $24.48
502	WE2M174	Screw #10	$10.50 Special Order
630	WE1M650	Connector Motor	$14.50 Special Order
	WE17X10010	Motor & Pulley Asm. (Replaces: WE17M22)	$182.80  In-Stock Retail: $383.76
803	WD21X10261	Switch Interlock (Replaces: WD21X557)	$21.80  In-Stock Retail: $21.25
