Whirlpool WFW95HEXW1 Parts List

Popular Searches: (Click to search)    12oz  2oz  accessory  complete  control  door  flowmeter  hoses  inlet  kit  motor  paint  parts  pressurized  pump  spray  touch  unit  valve  white


Select a Diagram

01 - Top And Cabinet Parts

02 - Door Parts

03 - Control Panel Parts

04 - Dispenser Parts

05 - Tub And Basket Parts

06 - Pump Parts

07 - Optional Parts (not Included)

Select Diagram ... 01 - Top And Cabinet Parts 02 - Door Parts 03 - Control Panel Parts 04 - Dispenser Parts 05 - Tub And Basket Parts 06 - Pump Parts 07 - Optional Parts (not Included)

03 - Control Panel Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	W10369550	Console Asssembly (white)	$251.20 Special Order
	WPW10388438	Console Asssembly (red)	$304.10 Special Order
	W10388436	Console Asssembly (silver)	$304.10 Special Order
2	W10839403	Handle, Dispenser Drawer (includes Badge) (white)	$56.40 Special Order
	W10327027	Handle, Dispenser Drawer (includes Badge) (silver)	Call for Availability
	W10316352	Handle, Dispenser Drawer (includes Badge) (red)	$48.90 Special Order
3	W10117943	Badge, Whirlpool	$11.80 Special Order
4	W10388203	Control Unit, Central	$273.20 Special Order
5	W10267937	Harness, Jumper	$9.40 Special Order
6	W10267938	Harness, Jumper Ui	$9.20 Special Order
7	W10208197	Bracket, Console	$109.80 Special Order
8	WP489464	Screw	$4.80 Special Order
9	WPW10653575	Channel, Water	$55.70 Special Order
10	W10317566	Clip, Spring	$6.60 Special Order
11	W10271988	Harness, Main Ui	$168.40 Special Order
12	W10271980	Harness, Wiring (upper Main)	$173.00 Special Order
13	WPW10251394	Assembly, Control Knob (chrome) (Replaces: W10251394)	$35.90 Special Order
14	W10444479	Ui, Center (includes Knob)	$126.90 Special Order
