Whirlpool WFW94HEXL0 Parts List

Popular Searches: (Click to search)    12oz  2oz  accessory  central  complete  control  door  hoses  inlet  kit  lock  paint  parts  pressurized  pump  spray  stack  touch  unit  white


Select a Diagram

01 - Top And Cabinet Parts

02 - Door Parts

03 - Control Panel Parts

04 - Dispenser Parts

05 - Tub And Basket Parts

06 - Pump Parts

07 - Optional Parts (not Included)

Select Diagram ... 01 - Top And Cabinet Parts 02 - Door Parts 03 - Control Panel Parts 04 - Dispenser Parts 05 - Tub And Basket Parts 06 - Pump Parts 07 - Optional Parts (not Included)

04 - Dispenser Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WPW10289387	Valve, Water Inlet (Replaces: W10289387)	$130.40  In-Stock Retail: $127.16
2	W10538835	Hose, Inlet Valve To Dispenser	$17.50 Special Order
3	WP596669	Clamp, Hose	$4.80 Special Order
4	WP8183181	Nozzle, Inlet	$58.90  In-Stock Retail: $57.41
5	WP8183183	Lever, Connection (Replaces: 8183183)	$56.90 Special Order
6	WP8183184	Cam, Actuator	$56.90  In-Stock Retail: $55.42
7	WPW10183517	Lever, Water Distribution   (Replaces: W10183517)	$8.30 Special Order
8	WPW10352973	Actuator	$110.10  In-Stock Retail: $107.36
9	WP8540282	Screw (Replaces: 8540282)	$7.60  In-Stock Retail: $7.38
10	WPW10259003	Housing, Dispenser Assembly (Replaces: W10259003)	$139.90 Special Order
11	WP8181712	Nozzle, Distribution	$56.20 Special Order
12	WPW10121596	Separator, With Selection Slider	$47.70 Special Order
13	W10289432	Siphon, Bleach/softener	$52.90 Special Order
14	W10003140	Cover, Detergent Drawer	$53.40 Special Order
15	WPW10256686	Drawer, Detergent (complete)   (Replaces: W10256686)	$76.80  In-Stock Retail: $74.89
16	W10839403	Handle, Dispenser Drawer (includes Badge) (white) (Replaces: W10311731)	$52.70  In-Stock Retail: $51.35
	W10316353	Handle, Dispenser Drawer (includes Badge) (red)	$37.70 Special Order
	W10327028	Handle, Dispenser Drawer (includes Badge) (silver)	$35.40 Special Order
17	W10117943	Badge, Whirlpool	$11.80 Special Order
18	W10239910	Clamp, Hose	$35.50 Special Order
19	WPW10239966	Hose, Dispenser To Bellow	$52.30 Special Order
