Maytag 9524XPB Parts List

Popular Searches: (Click to search)    blk  door  glass  handle  horizontal  inner  lower  oven  rack  seal  thermostat


Select a Diagram

01 - Body

02 - Control Panel

03 - Door (lower)

04 - Door (upper)

Select Diagram ... 01 - Body 02 - Control Panel 03 - Door (lower) 04 - Door (upper)

03 - Door (lower)   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	3601F102-51	Baffle, Upper Door (Series: 01)	$31.50 Special Order
2	7112P093-60	Clip, Glass Retainer (blk) (Series: 01)	$8.10 Special Order
3	WP7101P126-60	Screw, No.10-16ab (Series: 01)	$4.80 Special Order
	12001422	Tape (Series: 01)	$4.40 Special Order
4	2401F104-70	Panel, Door (blk) (Series: 01)	Call for Availability
5	3603F013-80	Frame, Window----na (Series: 01)	Call for Availability
6	74009406	Glass, Inner (Series: 01)   (Replaces: 7902P386-60)	$45.80 Special Order
7	WP854334	Seal, Rubber (Series: 01)	$7.90 Special Order
	7208P001-60	Seal, Glass (Series: 01)	$4.40 Special Order
	7902P335-60	Glass, Outer (blk) (Series: 01)	Call for Availability
8	WP7701P024-60	Handle, Door (blk) (Series: 01)   (Replaces: 7701P024-60)	Call for Availability
9	2402W132-19	Lining, Door (Series: 01)	Call for Availability
10	WP7212P007-60	Seal, Door (vertical) (Series: 01)	$71.70  In-Stock Retail: $69.86
11	WP7212P006-60	Seal, Door (horizontal) (Series: 01) (Replaces: 7212P006-60)	$70.80 Special Order
12	7002P019-60	Insulation, Door Lower (Series: 01)	$25.10 Special Order
13	74003986	Spacer, Glass (Series: 01)   (Replaces: 8010P016-60)	$8.40 Special Order
14	7101P089-60	Screw, Door Handle (Series: 01)	Call for Availability
15	8010P077-60	Spacer, Handle (wht) (Series: 01)	Call for Availability
