Maytag XRSS687BB (BOM: PXRSS687BB0) Parts List

Search Model by Keyword(s):

Popular Searches: (Click to search)    5``  blk  bucket  chute  clip  closure  crisper  crush  door  end  evaporator  fan  frame  ice  plastic  screw  speed  support  thermistor  tube


Select a Diagram


07 - Fz Door And Facade   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item # Part # Description Price / Availability Add to Cart
1 67004938 67004938 Assy, Waterline $82.10
Special Order
2 W10833902 Clamp, Tube $6.90
Special Order
67006425 67006425 Screw, Sm
(Replaces: M0238642)
$4.80
 In-Stock
Retail: $4.59
3 M0104102 M0104102 Clip, Cord $5.20
Special Order
4 WP12665101 WP12665101 Seal, Ice Chute
(Replaces: 12665101)
$4.50
Special Order
5 12563401 Insul, Chute Doorxx $0.40
Special Order
6 WP12562701 WP12562701 Door, Ice Chute
(Replaces: 12562701)
$4.80
Special Order
7 12002464 12002464 Hinge, Ice Chute $68.70
Special Order
8 WP12565502 Spring, Chute Dr   (Replaces: 12565502) $4.80
 In-Stock
Retail: $4.59
9 12002464 12002464 Extension, Ice Chute $68.70
Special Order
67006425 67006425 Screw, Sm
(Replaces: M0238642)
$4.80
 In-Stock
Retail: $4.59
10 67002816 Clip, Waterline $11.60
Special Order
11 M0360003 Bulb, Light $4.70
Special Order
12 12617501 Socket, Light $4.40
Special Order
13 67002170 Solenoid $62.10
Special Order
WP488234 WP488234 Screw, Mach $4.60
Special Order
14 67002309 Control, Facade Elec (blk) $93.70
Special Order
15 67004855 Facade, Elec(blk) $82.50
Special Order
16 B8385403 Spring, Sports Fill-return $4.40
Special Order
17 12665402B Button, Sports Fill (blk) $19.00
Special Order
18 M0237945 Screw,hi/lo $4.40
Special Order
WP12575502 WP12575502 Switch, Limit
(Replaces: 12575502)
$39.10
Special Order
19 12002331 12002331 Board, Low Voltage $256.00
Special Order
20 WP67001130 WP67001130 Plug $4.80
Special Order
21 67006425 67006425 Screw, Sm $4.80
 In-Stock
Retail: $4.59
