Whirlpool RF388LXGT3 Parts List

Popular Searches: (Click to search)    almond  biscuit  black  foot  front  hand  infinite  left  lower  paint  pressurized  rear  right  screw  side  spray  switch  touch  trim  white


Select a Diagram

01 - Cooktop, Literature

02 - Control Panel

03 - Chassis

04 - Door

05 - Drawer & Broiler, Optional

Select Diagram ... 01 - Cooktop, Literature 02 - Control Panel 03 - Chassis 04 - Door 05 - Drawer & Broiler, Optional

01 - Cooktop, Literature   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	LIT8053714	Literature Parts (instructions, Installation)	Call for Availability
	LIT3195945	Literature Parts (installation Instr (template))	Call for Availability
	LIT8053401	Literature Parts (guide, Use & Care)	Call for Availability
	LIT8053302	Literature Parts (tech Sheet)	Call for Availability
	LIT3191638	Safer Cooking Tips	Call for Availability
2	3149191	Spring, Locator	$7.20 Special Order
3	WP3196170	Screw	$4.80 Special Order
4	8053544	Cooktop (almond)	$373.20 Special Order
	8187851	Cooktop (white)	$412.20 Special Order
	8187852	Cooktop (biscuit)	$407.10 Special Order
5	8273334	Light, Indicator (hot Surface)	Call for Availability
6	3195810	Bracket, Ind Light	$4.40 Special Order
	WP3196175	Screw (2)	$4.80  In-Stock Retail: $4.59
7	WP8273993	Element, Surface (1800 W - Rr) (Replaces: 8273993)	$189.30  In-Stock Retail: $184.59
	W11047722	Element, Surface (2500 W - Lf)   (Replaces: 8273992)	$125.70  In-Stock Retail: $122.63
	W11171119	Element, Surface (1200 W - Rf)   (Replaces: WP8273994 8273994)	$182.10  In-Stock Retail: $177.65
9	3196455	Bracket, Element	$28.30 Special Order
10	WP3196557	Screw (Replaces: 3196169)	$4.80  In-Stock Retail: $4.59
