Whirlpool MH1140XMB4 Parts List

Popular Searches: (Click to search)    black  cam  capacitor  door  filter  grease  grille  handle  interlock  lamp  magnetron  micro  plate  screw  support  switch  top  turntable  vent  white


Select a Diagram

01 - Control Panel Parts

02 - Door Parts

03 - Interior And Ventilation Parts

04 - Air Flow Parts

05 - Magnetron And Turntable Parts

06 - Cabinet And Installation Parts

Select Diagram ... 01 - Control Panel Parts 02 - Door Parts 03 - Interior And Ventilation Parts 04 - Air Flow Parts 05 - Magnetron And Turntable Parts 06 - Cabinet And Installation Parts

04 - Air Flow Parts   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	8205945	Deflector, Air	$35.90 Special Order
2	8185097	Socket, Motor Wire	$21.40 Special Order
3	8205563	Base Plate	$60.30 Special Order
4	8185098	Air Guide (right)	$26.80 Special Order
5	8183697	Thermostat   (Replaces: 4393945)	Call for Availability
6	8185099	Deflector, Cooling Air	$22.70 Special Order
7	8206232A	Lamp (Replaces: 8205586 8206443 4393681)	$5.20  In-Stock Retail: $4.99
9	W10117942	Motor, Fan (Replaces: 8184825)	Call for Availability
10	8205355	Shield	Call for Availability
11	8204996	Air Guide, Sealing Plate	$58.20 Special Order
13	8169474	Screw	$5.40 Special Order
14	8169478	Screw	$5.90 Special Order
15	W10841091	Screw	$5.70 Special Order
16	8185115	Air Guide (left)	$31.30 Special Order
17	8185118	Cover, Light	$4.40 Special Order
18	8169539	Holder, Lamp	$39.50 Special Order
19	8206624	Filter (Replaces: 8169561)	Call for Availability
