Maytag S136B Parts List

Popular Searches: (Click to search)

Select a Diagram

01 - Access Panel

02 - Blower Motor

03 - Blower Motor (cooling)

04 - Body

05 - Control Panel

06 - Internal Controls

07 - Liner

08 - Top Assembly

Double click the image below to zoom-in

Hover over In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability
1	703961	Panel, Control (blk) (Series: 1)	$82.00 Special Order
2	702388	Cap, End (lt) (Series: 1)	Call for Availability
3	Y702387	Cap, End (rt) (Series: 1)	$25.20 Special Order
4	W11120791	Switch, Infinite (Series: 1) (Replaces: WP7403P402-60 703650)	$88.70 In-Stock Retail: $86.44
6	Y704850	Switch, Selector (Series: 1)	$47.70 Special Order
8	Y703674	Thermostat (Series: 1)	Call for Availability
11	WP903115	Light, Surface Indicator 120v (Series: 1)	$4.80 Special Order
14	12200028	Clock (Series: 1)	$305.10 Special Order
	12200028	Clock (Series: 12)	$305.10 Special Order
15	WPW10339879	Tie, Cable (Series: 1)	$4.80 Special Order
17	702616	Bracket, Retaining (Series: 1)	Call for Availability
18	704608	Lens, Timer (wht) (Series: 1)	Call for Availability
19	22001403	Light, Oven Pilot (240v) (Series: 1)	$4.40 Special Order
20	3801F452-51	Bracket, Clock (Series: 1)	$4.40 Special Order
	703752	Wire, Resistor Therm. (Series: 1)	Call for Availability
	703523	Wire, Orange (right) (Series: 1)	Call for Availability
	704243	Wire, Brown (Series: 1)	Call for Availability
	704244	Wire, Blue (Series: 1)	Call for Availability
	703749	Wire, Orange (Series: 1)	Call for Availability
