Whirlpool LA5380XSW0 Parts List

Popular Searches: (Click to search)    and  brake  breakdown  clutch  complete  coupling  drive  for  further  isolation  mixing  motor  page  paint  pump  refer  tube  valve  water  white


Select a Diagram

02 - Top And Cabinet , Literature And Optional

03 - Controls And Rear Panel

04 - Agitator, Basket And Tub

05 - Miscellaneous

06 - Brake, Clutch, Gearcase, Motor And Pump

07 - Machine Base

08 - Wiring Harness

09 - Brake And Drive Tube

10 - Gearcase

11 - Water System

Select Diagram ... 02 - Top And Cabinet , Literature And Optional 03 - Controls And Rear Panel 04 - Agitator, Basket And Tub 05 - Miscellaneous 06 - Brake, Clutch, Gearcase, Motor And Pump 07 - Machine Base 08 - Wiring Harness 09 - Brake And Drive Tube 10 - Gearcase 11 - Water System

04 - Agitator, Basket And Tub   |   Back to Common Parts

Zoom In | Zoom Out | Zoom Full

Double click the image below to zoom-in

Hover over  In-Stock to see individual location availability

Item #	Part #	Description	Price / Availability	Add to Cart
1	WP3355758	Cap, Agitator	$4.80  In-Stock Retail: $4.59
2	WPW10109200	Screw (2)	$4.80  In-Stock Retail: $4.59
3	64213	Extension, Agitator	$69.90 Special Order
4	WP358237	Screw And Washer (Replaces: 358237)	$4.40  In-Stock Retail: $4.20
5	W10873800	Agitator   (Replaces: 64214)	$66.10 Special Order
6	W10880720	Tub Ring   (Replaces: 3976309 8528150 WPW10445870 63851)	$134.90  In-Stock Retail: $131.57
7	WP3976308	Gasket, Tub Ring (Replaces: 3359585 63852)	$17.40  In-Stock Retail: $16.89
8	WP21366	Nut, Spanner (Replaces: 21366)	$4.80  In-Stock Retail: $4.59
9	W10389328	Basket	$212.60  In-Stock Retail: $202.40
11	63849	Tub	$155.50 Special Order
13	WP389140	Block, Drive (Replaces: 389140)	$16.80  In-Stock Retail: $16.34
14	W10814296	Gasket, Center Post (Replaces: 383727)	$4.90  In-Stock Retail: $4.75
15	WP353244	Hose, Pressure Switch	$55.70  In-Stock Retail: $54.25
